RMQ-Titan pilot devices
Potentiometers, acoustic devices
2010 CA08103002Z-EN
www.eaton.com2/27
Potentiometers,acousticdevices
Bezel: Silver
Bezel: black
Circuit
Symbol
Resistance
Part no.
Article no.
Price
See price list
Std. pack
Part no.
Article no.
Price
See price list
Std. pack
R
kΩ
Potentiometer, IP66
￫Engineering
Bezel gold-plated
￫Page 2/48
Three separate screw
connections, P
max
= 0.5 W
Accuracy of resistance
value: ± 10% (linear)
M22…RH with large
operating head
1
M22-R1K
2)
229489
1 off
M22S-R1K
2)
232231
1 off
4.7
M22-R4K7
2)
229490
M22S-R4K7
2)
232232
10
M22-R10K
3)
229491
M22S-R10K
3)
232233
47
M22-R47K
2)
229492
M22S-R47K
2)
232234
100
M22-R100K
2)
229493
M22S-R100K
2)
232235
470
M22-R470K
2)
229494
M22S-R470K
2)
232236
Selectable +
Notes
1)
M22-R*-*
2)
263371
M22S-R*-*
2)
263372
Selectable +
Notes
1)
M22-R*-*-RH
2)
288863
Notes
1)
When ordering, the type reference must include the
following details:
First wildcard ≙ Resistance
2nd wildcard ≙ Standard scale/inscription
Information relevant for export to North America
2)
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05;
CSA-C22.2 No. 94-91; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
3)
Product Standards IEC/EN 60947-5-1; UL 508; CSA-22.2 No. 14-05;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection IEC: IP 66; UL/CSA Type: 3R, 4X, 12, 13
Bezel: Silver
Bezel: black
Information relevant for export to
North America
Part no.
Article no.
Price
Seeprice
list
Std. pack
Part no.
Article no.
Price
Seeprice
list
Std. pack
Compact acoustic device, IP40
Front black, without
buzzer, BA 9s lamp
socket
M22-AMC
229015
1 off
Product Standards IEC/EN 60947-5;
UL 508; CSA-C22.2
No. 14-05; CSA-
C22.2 No. 94-91;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification UL Listed,
CSA certified
Degree of Protection UL/CSA Type 3R,
4X, 12, 13
Buzzer for acoustic device
for BA 9s base
83 dB/10 cm,
18 - 30 mA,
positive pole at X1,
f = 2300 Hz
Continuous tone,
18 – 30 V AC/DC
M22-XAM
229025
1 off
Product Standards IEC/EN 60947-5;
UL 508;
CSA-C22.2 No. 14-
05; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification UL Listed,
CSA certified
Pulsedtone,24VDC
(+10 %/-15 %)
M22-XAMP
229028
1 off
ATEX
Z1
Z2
*
– *:
*
=
Available resistance value:
1K = 1 k
2K2 = 2.2 k
4K7 = 4.7 k
10K = 10 k
22K = 22 k
47K = 47 k
100K = 100 k
470K = 470 k
1M = 1 M
*
– *:
*
=
Standard scale/inscription: X1000
No scale/label: „blank“
