2/32 RMQ-Titan pilot devices
Contact elements
2010 CA08103002Z-EN
www.eaton.comContactelementsFixingadapters,contactelement
Terminal
type
Contact configura-
tion: = Safety func-
tion through positive
opening according to
IEC/EN 60947-5-1
Circuit
symbol
Contact travel
diagram, hub in
connection with
front element
Configuration
Part no.
Article no.
Price
See price list
Std. pack
Double contact elements
Front fixing. When using M22-PV emergency switching-off pushbuttons… max. 2 contact elements = 4 normally
closed contacts / normally open contacts
Cage clamp 2 N/O
–
M22-CK20
107898
20 off
2 NC
–
M22-CK02
107899
1 N/O
1 NC
–
M22-CK11
107940
Complete modules
Assembly of contact element with screw terminals and mounting clamp, front fixing
Screw
terminals
1 N/O
1 NC
M22-AK11
216505
5 off
1 N/O
M22-AK10
216504
1 NC
M22-AK01
216503
Notes
Configuration of fixing adapter with sequence
numbers to EN 50013
x = Sequence number on fixing adapter
y = Function number on contact element
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection UL/CSA Type: -
.3
.4
.3
.4
0 3.6 5.5
.1
.2
.1
.2
0 1.2 5.5
.3
.4
.1
.2
0 1.2 3.6 5.5
21
22
13
14
0 1.2 2.8 5.5
1
6
4
3
2
5
13
14
0 2.8 5.5
1
6
4
3
2
5
21
22
0 1.2 5.5
1
6
4
3
2
5
xy
xy
M22-CK..., M2-AK...
