2/36 RMQ-Titan control circuit devices
Button plates for pushbuttons
2010 CA08103002Z-EN
Buttonplates forpushbuttons
Style Flat Style extended
Inscription or explanation For use with Color Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std. pack
Selection aid for pushbuttons
≦ 5 characters: letter height 5 mm, > 5 characters: letter height 3 mm
– M22(S)-D-X
M22(S)-DR-X
M22-DG-X
M22-XD-S
216421
M22-XDH-S
216428
10 off
– M22-XD-W
216422
M22-XDH-W
216429
– M22-XD-R
216423
M22-XDH-R
216430
– M22-XD-G
216424
M22-XDH-G
216431
– M22-XD-Y
216425
M22-XDH-Y
216432
– M22-XD-B
216426
M22-XDH-B
216433
– M22-XD-GR
132670
with customized inscription via
Labeleditor ￫Note
– M22-XD-*-*
216427
M22-XDH-*-*
216434
Zu M22-XD-S-D2
218184
M22-XDH-S-D2
218229
Auf M22-XD-S-D3
218185
M22-XDH-S-D3
218230
Ab M22-XD-S-D4
218186
M22-XDH-S-D4
218231
Aus M22-XD-R-D5
218187
M22-XDH-R-D5
218232
Ein M22-XD-S-D6
218188
M22-XDH-S-D6
218233
Entsperren M22-XD-B-D14
218189
M22-XDH-B-D14
218234
Vorwärts M22-XD-S-D15
218190
M22-XDH-S-D15
218235
Rückwärts M22-XD-S-D16
218191
M22-XDH-S-D16
218236
Heben M22-XD-S-D17
218192
M22-XDH-S-D17
218237
Senken M22-XD-S-D18
218193
M22-XDH-S-D18
218238
STOP M22-XD-R-GB0
218194
M22-XDH-R-GB0
218239
STOP M22-XD-S-GB0
218195
M22-XDH-S-GB0
218240
START M22-XD-G-GB1
218196
M22-XDH-G-GB1
218241
START M22-XD-W-GB1
218197
M22-XDH-W-GB1
218242
CLOSE M22-XD-S-GB2
218198
M22-XDH-S-GB2
218243
UP M22-XD-S-GB3
218199
M22-XDH-S-GB3
218244
DOWN M22-XD-S-GB4
218200
M22-XDH-S-GB4
218245
TEST M22-XD-S-GB9
218201
M22-XDH-S-GB9
218246
OFF M22-XD-R-GB5
218202
M22-XDH-R-GB5
218247
ON M22-XD-S-GB6
218203
M22-XDH-S-GB6
218248
Notes When ordering, state complete part no. M22-XD(H)-*-*:
1st wildcard ≙ color: ‐R, ‐G, ‐B, ‐W, ‐Y, ‐S -GR
2nd wildcard ≙ file name generated by Labeleditor ￫Engineering
Information relevant for export to North America
UL/CSA certification not required
Text size 3 mm: Text size 5 mm:
max. 8 characters in 1st line,
10 characters in 2nd line,
8 characters in 3rd line
Max. 5 characters per line
ABCD E FGH
ABCD E FGH
ABCD E FGHM Z A B C D E
M22-XD(H)... HPL02036EN
