Eaton Industrial Switchgear - xCommand Control & Indication

2/30 RMQ-Titan pilot devices

Illuminated selector switch actuator

2010 CA08103002Z-EN

www.eaton.com

Illuminated selectorswitchactuator

Bezel: Silver

Bezel: black

Function:

Color

Part no.

Article no.

Price

See price

list

Std. pack

Part no.

Article no.

Price

See price

list

Std. pack

= Momentary

= Maintained

Illuminated selector switch actuators, thumb-grip, IP66

￫Engineering

Bezel gold-plated￫Page 2/48

Maintained/momentary function, can be changed with coding

adapter M22-XC-Y￫ Engineering

Momentary

40°

White

M22-WLK-W

216812

5 off

M22S-WLK-W

216813

5 off

40°

Red

M22-WLK-R

216814

M22S-WLK-R

216815

40°

Green

M22-WLK-G

216816

M22S-WLK-G

216817

40°

Yellow

M22-WLK-Y

216818

M22S-WLK-Y

216819

40°

Blue

M22-WLK-B

216820

M22S-WLK-B

216821

Maintained

60°

White

M22-WRLK-W

216823

M22S-WRLK-W

216824

60°

Red

M22-WRLK-R

216825

M22S-WRLK-R

216826

60°

Green

M22-WRLK-G

216827

M22S-WRLK-G

216828

60°

Yellow

M22-WRLK-Y

216829

M22S-WRLK-Y

216830

60°

Blue

M22-WRLK-B

216831

M22S-WRLK-B

216832

3 positions

Momentary

40°40°

White

M22-WLK3-W

216833

5 off

M22S-WLK3-W

216834

5 off

40°40°

Red

M22-WLK3-R

216835

M22S-WLK3-R

216836

40°40°

Green

M22-WLK3-G

216837

M22S-WLK3-G

216838

40°40°

Yellow

M22-WLK3-Y

216839

M22S-WLK3-Y

216840

40°40°

Blue

M22-WLK3-B

216841

M22S-WLK3-B

216842

Maintained

60°60°

White

M22-WRLK3-W

216843

M22S-WRLK3-W

216844

60°60°

Red

M22-WRLK3-R

216845

M22S-WRLK3-R

216846

60°60°

Green

M22-WRLK3-G

216847

M22S-WRLK3-G

216848

60°60°

Yellow

M22-WRLK3-Y

216849

M22S-WRLK3-Y

216850

60°60°

Blue

M22-WRLK3-B

216851

M22S-WRLK3-B

216852

Selectable

￫Notes

M22-WRLK3-*/*

217438

M22S-WRLK3-*/*

217439

V position

60°

White

M22-WLKV-W

284393

5 off

M22S-WLKV-W

284398

5 off

60°

Red

M22-WLKV-R

284394

M22S-WLKV-R

284399

60°

Green

M22-WLKV-G

284395

M22S-WLKV-G

284540

60°

Yellow

M22-WLKV-Y

284396

M22S-WLKV-Y

284543

60°

Blue

M22-WLKV-B

284397

M22S-WLKV-B

284544

Notes

Information relevant for export to North America

Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking

UL File No.

E29184

UL CCN

NKCR

CSA File No.

012528

CSA Class No.

3211-03

NA Certification

UL Listed, CSA certified

Degree of Protection UL/CSA Type 3R, 4X, 12, 13

ATEX

Example: M22-WRLK3-*/*

/*:

= 1 for

or 2 for

= Color

M22-W(R)LK...
