2/46 RMQ-Titan control circuit devices

Surface mounting enclosures

2010 CA08103002Z-EN

Mounting

locations

Cable entry knockouts

Color

RAL value

Protection

type

Part no.

Article no.

Price

See price

list

Std. pack

Floor

Pages

Number

Number ×M… Number ×M…

M20 connecting screw

For connection of any M22-I... surface mounting enclosures

Mounting by M20 cable entry from the side

–

–

–

–

–

IP67

M22-XI

229162

25 off

M20 metric cable glands according to EN 50262

With lock nut and built-in strain relief

Polyamide, halogen free

External diameter of cable 6 - 13 mm

–

–

–

–

–

IP68, IP69K

V-M20

206910

20 off

Surface mounting enclosures

Including mounting plate for base fixing

Enclosure base: anthracite

12

2 x 32/25

2 x 20

4 x 32/25

RAL 7035

IP55

M22-I12

222688

1 off

Notes

Information relevant for export to North America

Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking

UL File No.

E29184

UL CCN

NKCR

CSA File No.

012528

CSA Class No.

3211-03

NA Certification

UL Listed, CSA certified

Degree of Protection UL/CSA Type 3R, 4X, 12, 13

M22

HPL02046EN
