4/94 Cam switches, switch-disconnectors

Cam switches

2010 CA08103002Z-EN

www.eaton.com

Camswitches

T0-...

T3-...

General

Standards

IEC/EN 60947, VDE 0660, IEC/EN 60204, CSA, UL,

Switch-disconnectors to IEC/EN 60947-3

Load-break switch according to IEC/EN 60947-3

Lifespan, mechanical

Operations

x 10

6

0.5

0.5

Maximum operating frequency

Operations/h

3000

3000

Climatic proofing

Damp heat, constant, to IEC 60068-2-78;

Damp heat, cyclic to IEC 60068-2-30

Ambient temperature

Open

°C

-25 - 50

-25 - 50

Enclosed

°C

-25 - 40

-25 - 40

Mounting position

Any

Any

Mechanical shock resistance to IEC 60068-2-27

Half-sinusoidal

shock 20 ms

g

> 15

> 15

Contacts

Rated operational voltage

U

e

V AC

690

690

Rated impulse withstand voltage

U

imp

V AC

6000

6000

Overvoltage category/pollution degree

III/3

III/3

Rated uninterrupted current

Open

I

u

A

20

32

Enclosed

I

u

A

20

32

Load rating with intermittent operation, class 12

AB 25 % DF

x I

e

2

2

AB 40 % DF

x I

e

1.6

1.6

AB 60 % DF

x I

e

1.3

1.3

Short-circuit rating

Fuse

A gG/gL 20

35

Rated short-time withstand current (1 s current)

I

cw

A

rms

320

650

Safe isolation according to EN 61140

Between the contacts

V AC

440

440

Switching angle

°

90

60

45

30

90

60

45

30

Contact units

Max. 11

Max. 11

Contacts with double-break

Max. 22

Max. 22

Current heat loss per contact at I

e

W 0.6

1.1

Terminal capacity

Solid or stranded

mm

2

1 x (1 - 2.5)

2 x (1 - 2.5)

1 x (1 - 6)

2 x (1 - 6)

Flexible with ferrule to DIN 46228

mm

2

1 x (0.75 - 1.5)

2 x (0.75 - 1.5)

1 x (0.75 - 4)

2 x (0.75 - 4)

Flat terminal for rails

mm

2

Terminal screw

M3.5

M4

Tightening torque

Nm

1

2

Notes

The following applies for mechanical shock resistance: T3.../I... >12g

Applies to T0(3).../SVB: isolating characteristics to IEC/EN 60947 for rated operational voltage

U

e

up to 500 VAC

The following applies to rated uninterrupted current

I

u

of contacts: max. 95 A with T5-4-8344/I5

The following applies for solid, stranded and flexible terminal capacities:

T0(3), (6), (8)...: if 2 conductors are used, a max. difference of 2 cross-section sizes is permissible

T5(B)-...: if 2 conductors are used, a max. difference of one cross-section sizes is permissible

The following applies for part no. T8-3-8342/...: switching angle = 90° and flat conductor connection = 1 flat conductor,

25 x 5, or 2 flat conductors, 20 x 3
