4/96 Cam switches, switch-disconnectors
Cam switches
2010 CA08103002Z-EN
www.eaton.comCamswitches
T0-...
T3-...
Switching capacity
AC voltage
Rated making capacity cos ϕ = 0.35
A
130
320
Rated breaking capacity,
Motor load switch cos ϕ = 0.35
230 V
A
100
260
400 V
A
110
260
500 V
A
80
240
690 V
A
60
170
Rated operational current
load break switch AC-21A
440 V
I
e
A
20
32
Motor rating
Motor load switch AC-3
230 V
P
kW 3
6.5
230 V star-delta
P
kW 4
11
400/415 V
P
kW 4
12
400 V star-delta
P
kW 5.5
18.5
500 V
P
kW 5.5
15
500 V star-delta
P
kW 7.5
22
690 V
P
kW 4
15
690 V star-delta
P
kW 5.5
22
Motor rating
Motor load switch AC-23A
230 V
P
kW 3.5
7.5
400/415 V
P
kW 6.5
13
500 V
P
kW 7.5
15
690 V
P
kW 6.5
15
Rated operational current
Control switch AC-15
230 V
I
e
A
6
10
400/415 V
I
e
A
4
6
500 V
I
e
A
2
4
DC voltage
DC-1, load switch L/R = 1 ms
Rated operational current
I
e
A
10
25
Voltage per contact connected in series
V
60
60
DC-21A
Rated operational current 240 V I
e
A
1
1
240 V contacts
Number
1
1
DC-23A, motor load switch
L/R = 15 ms
24 V Rated operational current
I
e
A
10
25
Contacts
Number
1
1
48 V Rated operational current
I
e
A
10
25
Contacts
Number
2
2
60 V Rated operational current
I
e
A
10
25
Contacts
Number
3
3
120 V Rated operational current
I
e
A
5
12
Contacts
Number
3
3
240 V Rated operational current
I
e
A
5
5
Contacts
Number
5
5
DC-13, control switch L/R = 50 ms
Rated operational current
I
e
A
10
20
Voltage per contact connected in series
V
32
32
Control circuit reliability at 24 V DC, 10 mA
Fault probability
H
F
< 10
-5
, < 1 failure for 100000 switching operations
Auxiliary contacts
Standards
Rated insulation voltage
U
i
V AC
–
–
Rated uninterrupted current
I
u
A
–
–
Rated operational current
AC-15 at 230 V
I
e
A
–
–
400 V/415 V
I
e
A
–
–
Short-circuit rating
Max. fuse
A gG/gL –
–
Terminal capacity
Solid
mm
2
–
–
Flexible with ferrule to DIN 46228
mm
2
–
–
Tightening torque
Nm
Control circuit reliability at 24 V DC, 10 mA
Fault probability
H
F
–
–
T
