Cam switches, switch-disconnectors
2010 CA08103002Z-EN
www.eaton.com4/93
Rating data for approved types
P5-125
P5-160
P5-250
P5-315
UL File No. E36332
Contacts
Rated operational voltage
U
e
V
600
600
600
600
Rated impulse withstand voltage
1)
U
imp
V AC
8000
8000
8000
8000
Rated uninterrupted current
2)
I
u
A
125
160
250
300
Rated operational current
Ampere rating
Off switch
I
e
A
125
2)
160
2)
250
2)
300
2)
Changeover
switches
I
e
A
125
2)
160
2)
–
–
Non inductive and slightly inductive loads
Rated switching duty
DOL rating (similar to AC-3)
3-phase, 3 pole
120 V
HP
15
20
30
40
240 V
HP
30
40
60
75
480 V
HP
60
60
75
100
600 V
HP
60
60
75
100
Short-circuit rating
Max. back-up fuse, gL characteristic
A
125
160
250
315
Rated short-time withstand current (1 s current)
A
2500
3000
4600
5800
Terminal capacity
Cu cable
Solid or stranded for box
terminal
AWG 3/0
3/0
–
–
MCM –
–
350
350
Flexible without ferrule
AWG 2/0
2/0
–
–
MCM –
–
300
300
Connection with cable lug or busbar
M10 x
M10 x
M12 x
M12 x
Terminal screw
mm 20
20
20
20
Max. width
mm 20
20
25
25
Max. width with terminal cover
mm 25
25
34
34
Ambient temperature
Open on 100 % I
u
/I
th
50
°
C over 24 hours with peaks up to 55 °C
Enclosed on 100% I
the
35
°
C over 24 hours with peaks up to 40 °C
Notes
1)
Valid for mains with grounded star point, overvoltage category III, pollution degree 3
2)
Valid for connection with cables for 75°C
HI11
HI21-P5-125(160)
HI21-P5-250(315)
Auxiliary contacts
Standards
Rated insulation voltage
U
i
V AC
600
600
Rated uninterrupted current
I
u
A
10
10
Rated operational current
I
e
Pilot Duty
P600
P600
P600
Heavy Pilot Duty
A600
A600
A600
General Use
10 A – 600 V AC
–
–
Ampere rating
Non inductive and slightly inductive loads
–
10
10
Short-circuit rating
Max. fuse
gL characteristic A
–
16
16
Terminal capacity
Solid or stranded
AWG
–
12
12
Flexible without ferrule
AWG
–
14
14
Notes
1)
Devices for world markets IEC ≙ UL/CSA
P5
