Switch-disconnectorsTechnical data
P1-25 P1-32 P3-63 P3-100
General
Standards IEC/EN 60947, VDE 0660, IEC/EN 60204, CSA, UL
switch-disconnector to IEC/EN 60947-3
Lifespan, mechanical Operations x 106 0.3 0.3 0.1 0.1
Maximum operating frequency Operations/h 50 50 50 50
Climatic proofing Damp heat, constant, to IEC 60068-2-78;
Damp heat, cyclical, to IEC 60068-2-30
Ambient temperature Open °C -25 - 50 -25 - 50 -25 - 50 -25 - 50
Enclosed °C -25 - 40 -25 - 40 -25 - 40 -25 - 40
Mounting position Any Any Any Any
Mechanical shock resistance
(IEC/EN60068-2-27)
Half-sinusoidal shock 20 ms g 15 15 15 15
Contacts
Rated operational voltage Ue V AC 690 690 690 690
Rated impulse withstand voltage Uimp V AC 6000 6000 6000 6000
Overvoltage category/pollution degree III/3 III/3 III/3 III/3
Rated uninterrupted current Iu A 25 32 63 100
Load rating with intermittent
operation, class 12
AB 60 % DF x Ie 1.3 1.3 1.3 1.3
AB 40 % DF x Ie 1.6 1.6 1.6 1.6
AB 25 % DF x Ie 2 2 2 2
Short-circuit rating Fuse A gG/gL 25 50 80 100
Rated short-time withstand current (1 s current) Icw Arms 640 640 1260 2000
Isolating characteristics to IEC/EN 60947 V AC ≦ 690 ≦ 690 ≦ 690 ≦ 690
Safe isolation according to EN 61140
Safe isolation to VDE 0106 Part 101 and Part 101 A1 between the
auxiliary contacts and main circuits
V AC 440 440 440 440
Switching angle ° 90 90 90 90
Contacts Number Max. 3 (+N) Max. 3 (+N) Max. 3 (+N) Max. 3 (+N)
Current heat loss per contact at Ie W 1.1 1.8 4.5 7.5
Terminal capacity
Solid or stranded mm2 1 x (1.5 - 6)
2 x (1.5 - 6)
1 x (1.5 - 6)
2 x (1.5 - 6)
1 x (2.5 - 35)
2 x (2.5 - 10)
1 x (2.5 - 35)
2 x (2.5 - 10)
Flexible with ferrule to DIN 46228 mm2 1 x (1 - 4)
2 x (1 - 4)
1 x (1 - 4)
2 x (1 - 4)
1 x (1.5 - 25)
2 x (1.5 - 6)
1 x (1.5 - 25)
2 x (1.5 - 6)
Terminal screw M4 M4 M5 M5
Tightening torque Nm 1.6 1.6 3 3
Switching capacity
AC voltage
Rated making capacity cos ϕ = 0.35 A 240 320 800 950
Rated breaking capacity,
motor load switch cos ϕ = 0.35
230 V A 190 260 640 760
400/415 V A 150 300 600 740
500 V A 170 290 590 880
690 V A 150 250 340 520
Rated operational current 440 V, load-break switch AC-21A Ie A 25 32 63 100
AC-3 motor load switch motor
rating
230 V P kW 5.5 7.5 15 22
400/415 V P kW 7.5 13 30 37
500 V P kW 7.5 18.5 30 45
690 V P kW 7.5 15 30 37
AC-23A motor load switch motor
rating
230 V P kW 7 8.5 18.5 30
400/415 V P kW 13 15 30 50
500 V P kW 11 18.5 37 65
690 V P kW 11 18.5 30 45
DC voltage
DC-1, load switch L/R = 1 ms Rated operational current Ie A 25 32 63 100
Voltage per contact connected in series V 60 60 60 60
DC-23A, motor load switch
L/R = 15 ms
24 V Rated operational current Ie A 25 25 50 50
Contacts Number 1 1 1 1
48 V Rated operational current Ie A 25 25 50 50
Contacts Number 2 2 2 2
60 V Rated operational current Ie A 25 25 50 50
Contacts Number 3 3 3 3
120 V Rated operational current Ie A 12 12 25 25
Contacts Number 3 3 3 3
Notes Main switch characteristics to IEC/EN 60204; positive opening of contacts, operator element positively located on shaft.
Rated uninterrupted current Iu is specified for max. cross-section.
For terminal capacity solid, stranded and flexible: Max. 2 cross-section sizes difference admissible when using 2 conductors.
P1, P3
