Cam switches, switch-disconnectors

Switch-disconnectors

2010 CA08103002Z-EN

www.eaton.com

4/91

Switch-disconnectors

Switch-disconnectors,auxiliarycontacts

P5-125

P5-160

P5-250

P5-315

General

Standards

IEC/EN 60947, VDE 0660, IEC/EN 60204, CSA, UL

Switch-disconnectors to IEC/EN 60947-3

Lifespan, mechanical

Operations x 10

6

0.1

0.1

0.08

0.08

Maximum operating frequency

Operations/h

50

50

50

50

Climatic proofing

Damp heat, constant, to IEC 60068-2-78;

Damp heat, cyclical, to IEC 60068-2-30

Ambient temperature

Open

°C

-25 - 50

-25 - 50

-25 - 50

-25 - 50

Enclosed

°C

-25 - 40

-25 - 40

-25 - 40

-25 - 40

Mounting position

Any

Any

Any

Any

Contacts

Rated operational voltage

U

e

V AC

690

690

690

690

Rated impulse withstand voltage

U

imp

V AC

8000

8000

8000

8000

Overvoltage category/pollution degree

III/3

III/3

III/3

III/3

Rated uninterrupted current

I

u

A

125

160

250

315

Load rating with intermittent operation,

class 12

AB 60 % DF

x I

e

1.3

1.3

1.3

1.3

AB 40 % DF

x I

e

1.6

1.6

1.6

1.6

AB 25 % DF

x I

e

2

2

2

2

Short-circuit rating

Fuse

A gG/gL 125

160

250

315

Rated short-time withstand current (1 s current)

I

cw

A

rms

2500

3000

4600

5800

Isolating characteristics to IEC/EN 60947

V AC

≦ 690

≦ 690

≦ 690

≦ 690

Safe isolation according to EN 61140

Safe isolation to VDE 0106 Part 101 and Part 101 A1 between the

auxiliary contacts and main circuits

V AC

440

440

440

440

Switching angle

°

90

90

90

90

Contacts

Number

Max. 3 (+N)

Max. 3 (+N)

Max. 3 (+N)

Max. 3 (+N)

Current heat loss per contact at I

e

W 8

10

13

16

Terminal capacity

Solid or stranded

mm

2

1 x (10 - 95)

2 x (10 - 35)

1 x (10 - 95)

2 x (10 - 35)

1 x (16 - 185)

2 x (16 - 70)

1 x (16 - 185)

2 x (16 - 70)

Copper strip, 1 flat conductor

Number of

layersxwidth

x thickness

mm 6 x 9 x 0.8

6 x 20 x 1

Copper strip, 2 flat conductors

mm –

6 x 9 x 0.8

6 x 20 x 1

Flexible with ferrule to DIN 46228

mm

2

1 x (16 - 70)

2 x (16 - 25)

1 x (16 - 70)

2 x (16 - 25)

1 x (25 - 120)

2 x (25 - 50)

1 x (25 - 120)

2 x (25 - 50)

Terminal screw

Hexagon

screw 5

Hexagon

screw 5

Hexagon

screw 6

Hexagon

screw 6

Tightening torque

Nm 14

14

16

16

Notes

Main switch characteristics to IEC/EN 60204; positive opening of contacts, operator element positively located on shaft

Rated uninterrupted current I

u

is specified for max. cross-section.

For terminal capacity solid, stranded, and flexible:

Max. 2 cross-section sizes difference admissible when using 2 conductores.

P5
