4/90 Cam switches, switch-disconnectors
Switch-disconnectors
2010 CA08103002Z-EN
Switch-disconnectors
Rating data for approved types1)
UL File No. E36332 P1-25 P1-32 P3-63 P3-100
Contacts
Rated operational voltage Ue V AC 600 600 600 600
Rated uninterrupted current Iu
Current rating A 20 30 60 100
Pilot Duty A 600P 600 A 600P 600 – –
Switching capacity
AC-3; max. rated power
40 – 60 Hz AC motors
3-phase 200 V AC HP 5 7½ 15 20
230 V AC HP 5 10 15 25
460 V AC HP 10 20 40 60
575 V AC HP 15 25 50 75
Single-phase 120 V AC HP 1½ 2 3 5
200 V AC HP 3 3 7½ 10
230 V AC HP 3 5 10 15
Short-circuit rating
Standard 600 V AC kA 5 5 10 10
With back-up fuse A 110 110 150 150
With circuit-breakers Part no. NZMH6 NZMH6 NZMH6 NZMH9
Current setting A 125 125 125 125
Disconnect in motor circuits 600 V AC kA 10 10 10 –
With back-up fuse Class 50 A/J 50 A/J 100 A 100 A
Terminal capacity
Terminal capacity
Cu cable Min./ AWG 14 14 14 14
Max. AWG 8 8 2 2
Tightening torque Max. in-lb 14.1 14.1 26.5 26.5
HI 11
Auxiliary contacts (1 N/O + 1 N/C)
Pilot Duty P 600
Heavy Pilot Duty A 600
General Use 10 A – 600 V AC
Notes 1) Devices for world markets IEC ≙ UL/CSA
UL File No:
UL approved protection types
E36332 UL/NEMA 3R1) UL/NEMA 12 UL/NEMA 13
Switch-disconnectors
P1-.../EA/SVB • • –
P1-.../V/SVB • • –
P3-.../EA/SVB • • •
P3-.../V/SVB • • •
Notes Details of protection types
1) NEMA recommendation
Part no.: P1 P3-63 P3-100
Mounting form
/E; /EA; /EZ
/Z; /V; /IVS
/I2 +NA-I2
105866
/I4 +NA-I4
105868
/I5 +NA-I5
105869
P1, P3
