4/92 Cam switches, switch-disconnectors
Switch-disconnectors, auxiliary contacts
2010 CA08103002Z-EN
www.eaton.comP5-125
P5-160
P5-250
P5-315
Switching capacity
AC voltage
Rated making capacity cos ϕ = 0.35
A
850
1050
1700
2050
Rated breaking capacity,
motor load switch cos ϕ = 0.35
230 V
A
800
900
1600
1800
400 V
A
750
850
1380
1650
500 V
A
650
850
1250
1550
690 V
A
340
340
400
400
Rated operational current 440 V, load-break switch AC-21A
I
e
A
125
160
250
315
Motor rating
motor load switch AC-3
230 V
P
kW 22
30
37
45
400 V
P
kW 37
45
55
75
690 V
P
kW 30
37
45
45
Motor rating
motor load switch AC-23 A
230 V
P
kW 30
30
37
55
400 V
P
kW 45
55
90
110
690 V
P
kW 37
37
45
45
DC voltage
DC-1, load switch L/R = 1 ms
DC-1, load switch L/R = 1 ms
Rated operational current
I
e
A
125
160
250
315
Voltage per contact connected in series
V
42
42
42
42
DC-23A, motor load switch
L/R = 15 ms
24 V Rated operational current
I
e
A
125
160
250
315
Contacts
Number
3
3
3
3
48 V Rated operational current
I
e
A
125
160
250
315
Contacts
Number
3
3
3
3
60 V Rated operational current
I
e
A
125
160
250
315
Contacts
Number
3
3
3
3
120 V Rated operational current
I
e
A
40
50
80
100
Contacts
Number
3
3
3
3
Notes
Main switch characteristics to IEC/EN 60204; positive opening of contacts, operator element positively located on shaft
Rated uninterrupted current I
u
is specified for max. cross-section.
For terminal capacity solid, stranded, and flexible:
Max. 2 cross-section sizes difference admissible when using 2 conductores.
HI...-P1(P3)...
HI...-P5...
Auxiliary contacts
Standards
Control circuit isolator to IEC/EN 60947-5
Rated insulation voltage
U
i
V AC
500
500
Rated uninterrupted current
I
u
A
10
10
Rated operational current
AC-15 at 230 V
I
e
A
6
6
400 V/415 V
I
e
A
–
3
DC-13
125 V
I
e
A
1.1
0.23
250 V
I
e
A
0.55
0.1
Short-circuit rating
Max. fuse
A gG/gL
10
10
Terminal capacity
Solid
mm
2
1 × 0.75 - 2.5
2 × 0.75 - 1.5
1 × 0.75 - 2.5
2 × 0.75 - 1.5
Flexible with ferrule to DIN 46228
mm
2
1 × 0.5 - 1.5
2 × 0.5 - 1.5
1 × 0.5 - 1.5
2 × 0.5 - 1.5
Tightening torque
Nm
0.6
0.8
Control circuit reliability at 24 V DC, 10 mA
Fault probability
H
F
< 10
-5
, < 1 failure for 100 000 switching operations
