General
Standards
IEC/EN 60947, VDE 0660 UL, CSA
Control switch to IEC/EN 60947-5-1
Control circuit isolators to IEC/EN 60947-5-1
Control circuit isolator (IEC/EN 60947-5-1)
Max. 6 contacts; switching angle: 90°
Lifespan, mechanical
Operations
x 10
6
> 1
Maximum operating frequency
Operations/h
3000
Climatic proofing
Damp heat, constant, to IEC 60068-2-78;
Damp heat, cyclical, to IEC 60068-2-30
Ambient temperature
Open
°C
-25.…50
Enclosed
°C
-25.…40
Mounting position
Any
Terminal capacity
Solid
mm
2
1 x 1.5
2 x 1.5
Flexible without ferrule
mm
2
1 x 1.5
2 x 1.5
Solid or stranded
AWG 1 x 14
2 x 14
Flexible
AWG 1 x 16
2 x 16
Terminal screw
M2.5
Tightening torque
Nm 0.35
Contacts
Mechanical data
Contacts
Number Max. 16
Contact units (BE)
Max. 8
Switching angle
°
90
60
45
30
Smallest switching angle for ON-OFF-ON
°
60
Max. switch position
≦ 12
Electrical characteristics
Rated operational voltage
U
e
V AC 500
Rated impulse withstand voltage
U
imp
V AC 4000
Overvoltage category/pollution degree
III/3
Rated insulation voltage
U
i
V AC 500
Rated insulation voltage to UL/CSA
V AC 300
Rated uninterrupted current
I
u
A
10
Switching capacity
AC-23 motor load switch
230 V AC, 3 pole
kW 1.8
440 V AC, 3 pole
kW 3
230 V AC, 1 pole
kW 0.75
440 V AC, 1 pole
kW 1.1
AC-15 control switch
230 V AC, 1 pole
A
2.5
400 V AC, 1 pole
A
1.5
440 V AC, 1 pole
A
1
DC-13, control switch L/R = 50 ms Rated operational current
I
e
A
3
Voltage per contact connected in series
V
32
Switching capacity
(UL489, CSA 22.2 No. 5.1)
240 V AC, 3 pole
HP
1
277 V AC, 1 pole
HP
¾
300 V AC Heavy duty
A
10
Max. short-circuit protective device
Fuse
A gG/gL 10
Control circuit reliability at 24 V DC, 10 mA
Fault probability H
F
< 10
-5
, < 1 failure for 100000 switching cycles
