Cam switches, switch-disconnectors
Coupling drive, interlock parts, shaft extension
2010 CA08103002Z-EN
4/65
Couplingdrive, interlockparts, shaftextension
For use with Part no.
Article no.
Price
See
price
list
Std. pack Notes Information rele-
vant for export to
North America
Service distribution board mounting accessories
Including push-fit shaft
For retrofitting in service
distribution board mounting
T0-…/IVS design. Use the basic
switch's front plate.
T0-…/XZ IVS-T0
091114
1 off UL/CSA certifica-
tion not required
Coupling drive
Including push-fit shaft
For the retrofitting of switch
T0(T3)‐.../XZ as rear mounting,
spare part for T0(T3)/(P1)‐.../Z
– DE-T0
093487
1 off UL/CSA certifica-
tion not required
For the conversion of T5(B)‐.../E
flush mounting switch to rear
mounting, spare part for
T5(B)/(P3)‐...Z
– DE-P3
093972
3 off
Interlock sections
With PE and neutral conductor connection
Mounting on the back of flush mounting switch, with interlock function in
rear mounting switches.
T0-…/E, …EZ, …Z
T3-…/E, …EZ, …Z
P1-…/E, …EZ, …Z
UV-T0
019925
1 off Mounting on the
back of flush
mounting switch
UL/CSA certifica-
tion not required
T5(B)-…/E, …Z
P3-…/E, …Z
UV-P3
048289
1 off With interlock
function for rear
mounting switches
Interlock extensions
A max. of 4 units can be plugged on the interlock section every 25 mm
(an equal number of shaft extensions is required for this)
Use only with T0/T3-… and
P3-…/Z designs
UV-T0 ZVV-T0
022298
10 off – UL/CSA certifica-
tion not required
Use only with T5(B)-…/Z and
P3-…/Z designs
UV-P3 ZVV-P3
024671
10 off –
Shaft extensions
A max. of 4 units can be put on the switch shaft every 25 mm
T0-…/Z, T0-…/V
T3-…/Z, T3-…/V
P1-…/Z, P1-…/V
ZAV-T0
027044
10 off – UL/CSA certifica-
tion not required
T5(B)-…/Z
P3-…/Z
P3-…/V
ZAV-P3
029417
10 off –
Shaft
Aluminum, length: 480 mm P5-…/V…
P5-…/Z
ZAV-P5
280979
1 off UL/CSA certifica-
tion not required
Interlock extensions und shaft extensions, complete
Extension to 25 mm
When ordering with basic unit
+ZAV(X1)+ZVV(X1)-T0/P3
254546
1 off UL/CSA certifica-
tion not required
Control cable terminal
P5-250/315 ST-P5-250/315
280978
1 off Terminal capacity:
• Solid or stranded:
4 mm2
• Flexible with
ferrules to
DIN 46228: 4 mm 2
UL/CSA certifica-
tion not required
DE-T0(P3), ZAV-T0(P3) HPL04065EN
