4/64 Cam switches, switch-disconnectors
Neutral conductor, auxiliary contact, mounting accessories
2010 CA08103002Z-EN
Neutralconductor,auxiliarycontact,mountingaccessories
For use with Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Neutral conductor
Early-make on switching, late-break off switching
The N contact always behaves as an early-make contact when
switching on and as a late-break contact when switching off.
N-P1(P3)… switching capacity same as for contacts P1(P3)-…
For left or right side
mounting
P1-…/E, …/EA, …/EZ N-P1E
000651
5 off Product Standards UL 508; CSA-C22.2 No. 14-05;
IEC/EN 60947-3; CE marking
UL File No. CSA report applies to both
Canada and US
UL CCN –
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
For P1-…/I2: optionally,
N-P1Z or HI11-P1/P3Z,
can only be fitted on the
left
P1-…/Z, …/V, …/I2, …/IVS N-P1Z
000652
Product Standards UL 508; CSA-C22.2 No. 14-05;
IEC/EN 60947-3; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
P3-…/E, …/EA… N-P3E
062432
P3-…/Z, …/V, …/IVS
P3-63…/Z, …/I4
P3-100…/Z, …/I5
N-P3Z
064805
Neutral terminal
Front mounting, left
Service distribution board mounting, right
P5-125(160)/E(EA) N-P5-125/160E
280969
1 off
P5-125(160)/Z(V) N-P5-125/160Z
280970
P5-250(315)/E(EA) N-P5-250/315E
280971
P5-250(315)/Z(V) N-P5-250/315Z
280972
Ground terminal
Front mounting, right
Service distribution board mounting, left
P5-125(160)/E(EA) PE-P5-125/160E
280973
1 off
P5-125(160)/Z(V) PE-P5-125/160Z
280974
P5-250(315)/E(EA) PE-P5-250/315E
280975
P5-250(315)/Z(V) PE-P5-250/315Z
280976
Auxiliary contacts
1 normally open (N/O), 1 normally close contact (N/C)
Late-break on switching, early-make off switching. The N/O is always
connected as a load-shedding contact.
For left and/or right side
mounting
P1-…/E, …/EA…, …/EZ
P3-…/E, …/EA
HI11-P1/P3E
061813
5 off Product Standards UL 508; CSA-C22.2 No. 14-05;
IEC/EN 60947-5; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
For P1…/I2: optionally,
HI11-P1/P3ZorN-P1Z,can
only be fitted on the left
P1-…/Z, …/V, …/I2, …/IVS
P3-63/Z, …/V, …/I4, …/IVS
P3-100/Z, …/V, …/I5, …/
IVS
HI11-P1/P3Z
062031
5 off
2 normally open (N/O), 1 normally close contact (N/C)
For left and/or right side
mounting
P5-125(160)/E(EA) HI21-P5-125/160E
280963
1 off
P5-125(160)/Z(V) HI21-P5-125/160Z
280964
P5-250(315)/E(EA) HI21-P5-250/315E
280965
P5-250(315)/Z(V) HI21-P5-250/315Z
280966
Center mounting accessories
For single-hole fitting 22.3 mm
For cam switches with
existing front plate - quick
installation with snap
fitting system
T0-…/E
T3-…/E
EZ-T0
081622
1 off UL/CSA certification not required
Mounting diameter 22.3
mm, one man mounting
with screw fixing
T0-…/E
T3-…/E
P1-…/E
EZ-P1
091455
1 off
N-P1, N-P3, N-P5 HPL04064EN
