4/70 Mini cam switches
Control circuit isolators, ON/OFF switches
2010 CA08103002Z-EN
www.eaton.comControlcircuit isolators,ON/OFF switches
Flush mounting
Center mounting
Front IP65
Front IP65
Contact sequence
Front plate
no.
Pole
Part no.
Article no.
Price
See
price
list
Std. pack
Part no.
Article no.
Price
See
price
list
Std. pack
Control circuit isolators, 90°
with padlocking feature
Lockable in the 0 (Off) position
Up to 250 V AC per contact
1
TM-1-8290/E/SVB
045477
1 off
1
TM-1-8290/E/SVB-SW
215351
2
TM-1-8291/E/SVB
045478
2
TM-1-8291/E/SVB-SW
215352
3
TM-2-8292/E/SVB
045484
3
TM-2-8292/E/SVB-SW
210955
3 + N
TM-2-8293/E/SVB
045485
6
TM-3-8326/E/SVB
045498
On-Off switches, 90°
1
TM-1-8290/E
070131
1 off
TM-1-8290/EZ
000693
1 off
2
TM-1-8291/E
072504
TM-1-8291/EZ
015073
3
TM-2-8292/E
074877
TM-2-8292/EZ
015096
3 + N
TM-2-8293/E
077250
TM-2-8293/EZ
045486
6
TM-3-8326/E
079623
Information relevant for export to North America
Product Standards UL 508; CSA-C22.2 No. 14-05; IEC/EN 60947-3;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Listed, certified by UL for use in Canada
1
2
0 1
