Mini cam switches
Changeover switches
2010 CA08103002Z-EN
www.eaton.com4/71
Changeover switches
Flush mounting
Center mounting
Front IP65
Front IP65
Contact sequence
Front plate
no.
Pole
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
Changeover switches without 0 (Off) position 60°
1
TM-1-8220/E
081996
1 off
TM-1-8220/EZ
000692
1 off
2
TM-2-8221/E
084369
TM-2-8221/EZ
015197
3
TM-3-8222/E
086742
TM-3-8222/EZ
045493
4
TM-4-8223/E
089115
TM-4-8223/EZ
046119
5
TM-5-8369/E
091488
TM-5-8369/EZ
046126
6
TM-6-8370/E
093861
Changeover switches with 0 (Off) position 60°
1
TM-1-8210/E
096234
1 off
TM-1-8210/EZ
015137
1 off
2
TM-2-8211/E
098607
TM-2-8211/EZ
015166
3
TM-3-8212/E
010807
TM-3-8212/EZ
045491
4
TM-4-8213/E
013180
TM-4-8213/EZ
045847
Changeover switches with 0 (Off) position 90°
2
TM-2-8219/E
017926
1 off
3
TM-3-8299/E
020299
1 off
Information relevant for export to North America
Product Standards UL 508; CSA-C22.2 No. 14-05; IEC/EN 60947-3; CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Listed, certified by UL for use in Canada
1
2
3
4
1 2
