Mini cam switches
2010 CA08103002Z-EN
4/69
Product features
Contact chamber
• Rated uninterrupted current 10 A
• Positively opening contacts
• 1 – 2 contacts per contact chamber, up
to 16 contacts per switch
• For switching unequal potentials
• Control circuit reliability
Switch position
• Safety due to indexing
• Switching angles 30°, 45°, 60°, 90°
• Spring action with automatic return
with max. 6 contacts,
switching angle ≧ 60°
• Complete rotation
• If the total switching angle is 360°,
complete rotation possible in both
operating directions
Flush mounting (.../E) 1
Front IP65
Mounting from rear in panel
sides, plates or doors
Terminals
Crosshead screwdriver
Pozidriv
Finger proof
￫Page 4/70
Flush mounting control
circuit isolator (.../E/SVB)
1
Front IP65
TO IEC/EN 60 947-5, VDE 0660
0 position lockable with
2 padlocks 4 mm ⌀ or
1 padlock 6 mm ⌀
Can be used with up to
250 V AC per contact
Maximum 6 contacts
permissible
￫Page 4/70
Center mounting (.../EZ) 2
Front IP65
Mounted in 16.2 ⌀ or 22.3 ⌀
fixing hole, as specified in
IEC/EN 60 947-5-1, after the
included adapter is removed
￫Page 4/70
Key operation for
center mounting 3, 4
2 keys are supplied
Key withdrawable 90°
Key withdrawable 60° with
RONIS lock cylinder.
￫Page 4/77
Standard switches for
center mounting 5, 6
Black thumb-grip
￫Page 4/70
Control circuit isolators 7, 8
Red rotary handle and yellow
locking collar
Black rotary handle and black
locking collar
Lockable in the 0 position
￫Page 4/70
Standard switches for flush
mounting
9, 10
Black thumb-grip
￫Page 4/71
Standard switches
for IVS distribution board
mounting
11
Mounting in installation
distribution board
Overall width: 2 space units
(45 mm mounting depth)
Up to 2 contact units
