Optical sensorsE58Series
OpticalSensorsE58Series
Function Design
(outer
dimensions)
Rated
operational
voltage
Rated
switching
distance
S
n
mm
Switching
type
Connection
option
Material
Type of
light
Switching
principle
Part no.
Article no.
Price
See
price
list
Std. pack
E58 Series
Reflex sensor
With background suppression (Perfect Prox)
2-wire M18 x 1 18 - 50 V DC 50
–
plugconnector
M12 x 1
Stainless
steel
Visible
red
Dark
switching
E58-18DP50-DDP
135668
1 off
50
–
Light
switching
E58-18DP50-DLP
135669
100
–
Dark
switching
E58-18DP100-DDP
135662
100
–
Light
switching
E58-18DP100-DLP
135663
M30 x 1.5
150
–
Dark
switching
E58-30DP150-DDP
135674
150
–
Light
switching
E58-30DP150-DLP
135675
Information relevant for export to North America
Product Standards
UL 508; CSA-C22.2 No. 14;
IEC60947-5-2; CE marking
UL File No.
E166051
UL CCN
NRKH, NRKH7
CSA File No.
UL report applies to both Canada and US
CSA Class No.
–
NA Certification
UL Listed, certified by UL for use in Canada
Max. Voltage Rating
50 V DC
Degree of Protection
IEC: IP68, IP69K; UL/CSA Type: 1, 2, 3, 3R, 3S, 4, 4X, 6, 6P, 12, 12K, 13
Function Design
(outer
dimensions)
Rated
operational
voltage
Rated
switching
distance
S
n
mm
Switching
type
Connection
option
Material
Type of
light
Switching
principle
Part no.
Article no.
Price
See
price
list
Std. pack
E58 Series
Reflex sensor
With background suppression (Perfect Prox)
4-wire M18 x 1 10 - 30 V DC 50
NPN
PNP
2mconnection
cable
Stainless
steel
Visible
red
Dark
switching
E58-18DP50-HD
135670
1 off
50
NPN
PNP
plugconnector
M12 x 1
Dark
switching
E58-18DP50-HDP
135671
50
NPN
PNP
2mconnection
cable
Light
switching
E58-18DP50-HL
135672
50
NPN
PNP
plugconnector
M12 x 1
Light
switching
E58-18DP50-HLP
135673
100
NPN
PNP
2mconnection
cable
Dark
switching
E58-18DP100-HD
135664
100
NPN
PNP
plugconnector
M12 x 1
Dark
switching
E58-18DP100-HDP
135665
100
NPN
PNP
2mconnection
cable
Light
switching
E58-18DP100-HL
135666
100
NPN
PNP
plugconnector
M12 x 1
Light
switching
E58-18DP100-HLP
135667
M30 x 1.5 10 - 30 V DC 150
NPN
PNP
2mconnection
cable
Dark
switching
E58-30DP150-HD
135676
150
NPN
PNP
plugconnector
M12 x 1
Dark
switching
E58-30DP150-HDP
135677
150
NPN
PNP
2mconnection
cable
Light
switching
E58-30DP150-HL
135678
150
NPN
PNP
plugconnector
M12 x 1
Light
switching
E58-30DP150-HLP
135679
280
NPN
PNP
2mconnection
cable
Dark
switching
E58-30DPS280-HD
135680
280
NPN
PNP
plugconnector
M12 x 1
Dark
switching
E58-30DPS280-HDP
135681
280
NPN
PNP
2mconnection
cable
Light
switching
E58-30DPS280-HL
135682
280
NPN
PNP
plugconnector
M12 x 1
Light
switching
E58-30DPS280-HLP
135683
