Optical sensors 3/103
Technical data
Optical sensorsE65SMSeries
E65 SM Series
4-conductors, insulated material
10 - 30 V DC Diffuse reflective
sensor
Dark
switching
200 NPN
PNP
2 m connection
cable
E65-SMSD200-HD
135726
1 off
Dark
switching
200 NPN
PNP
plug connector
M12 x 1
E65-SMSD200-HDD
135727
Light
switching
200 NPN
PNP
2 m connection
cable
E65-SMSD200-HL
135728
Light
switching
200 NPN
PNP
plug connector
M12 x 1
E65-SMSD200-HLD
135729
Polarized reflex
photoelectric
sensor
For combination
with reflector
Dark
switching
3000 NPN
PNP
2 m connection
cable
E65-SMPR3-HD
135718
Dark
switching
3000 NPN
PNP
plug connector
M12 x 1
E65-SMPR3-HDD
135719
Light
switching
3000 NPN
PNP
2 m connection
cable
E65-SMPR3-HL
135720
Light
switching
3000 NPN
PNP
plug connector
M12 x 1
E65-SMPR3-HLD
135721
10 - 30 V DC Thru-beam
sensor (detector)
For combination
with sounce
Dark
switching
15000 NPN
PNP
2 m connection
cable
E65-SMTD15-HD
135730
1 off
Dark
switching
15000 NPN
PNP
plug connector
M12 x 1
E65-SMTD15-HDD
135731
Light
switching
15000 NPN
PNP
2 m connection
cable
E65-SMTD15-HL
135732
Light
switching
15000 NPN
PNP
plug connector
M12 x 1
E65-SMTD15-HLD
135733
Thru-beam
sensor (source)
For combination
with detector
– 15000 NPN
PNP
2 m connection
cable
E65-SMTS15-HA
135734
– 15000 NPN
PNP
plug connector
M12 x 1
E65-SMTS15-HAD
135735
Information relevant for export to North America Product Standards UL 508; CSA-C22.2 No. 14; IEC60947-5-2; CE marking
UL File No. E166051
UL CCN NRKH, NRKH7
CSA File No. UL report applies to both Canada and US
CSA Class No. –
NA Certification UL Listed, certified by UL for use in Canada
Max. Voltage Rating 30 V DC
Degree of Protection IEC: IP68, IP69K; UL/CSA Type: -
E65...-G... E65...-H... E65...15-H... E65...-HA...
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -25 - +55 -25 - +55 -25 - +55 -25 - +55
Protection type IP67 IP67 IP67 IP67
Mechanical shock resistance g 50
Shock duration 10 ms
Characteristic values
Rated operating voltage 18 - 264 V AC
18 - 50 V DC
10 - 30 V DC 10 - 30 V DC 10 - 30 V DC
Operating current in
the switched state at 24 V DC
Ib mA 20 20 20 40
Rated operational current Ie mA 200 100 100 –
Switching frequency Hz 31 500 – –
Switching state indication LED Red Red Red Red
Operating voltage display LED Green Green Green Green
Boundary gain Yellow Yellow Yellow Yellow
Protective functions Short-circuit protection
Protection against polarity reversal
Protection against wire breakage
Function 3-wire 4-wire 4-wire 4-wire
Construction type
Design (outer dimensions) 33 x 41 x 43 33 x 41 x 37 33 x 41 x 37 33 x 41 x 37
Material plastic plastic plastic plastic
Notes Further technical data can be found in the Online Catalogue at
Rated
operational
voltage
Function Switching
principle
Ratedswitching
distance
Sn
Switching
type
Connection
options
Part no.
Article no.
Price
See price
list
Std. pack
mm
