Optical sensorsE65SMSeries
Ordering
OpticalSensorsE65SMSeries
Rated
operational
voltage
Function
Switching
principle
Ratedswitching
distance
S
n
Switching
type
Connection
options
Part no.
Article no.
Price
See price
list
Std. pack
mm
E65 SM Series
3-conductors, insulated material
18 - 264 V AC
18 - 50 V DC
Reflex sensor
With background
suppression
(Perfect Prox)
Dark
switching
50
NPN (DC)
2 m connection
cable
E65-SMPP050-GD
135698
1 off
Dark
switching
50
NPN (DC)
plug connector
M12 x 1
E65-SMPP050-GDD
135699
Light
switching
50
NPN (DC)
2 m connection
cable
E65-SMPP050-GL
135700
Light
switching
50
NPN (DC)
plug connector
M12 x 1
E65-SMPP050-GLD
135701
Dark
switching
100
NPN (DC)
2 m connection
cable
E65-SMPP100-GD
135706
Dark
switching
100
NPN (DC)
plug connector
M12 x 1
E65-SMPP100-GDD
135707
Light
switching
100
NPN (DC)
2 m connection
cable
E65-SMPP100-GL
135708
Light
switching
100
NPN (DC)
plug connector
M12 x 1
E65-SMPP100-GLD
135709
Diffuse reflective
sensor
Dark
switching
200
NPN (DC)
2 m connection
cable
E65-SMSD200-GD
135722
Dark
switching
200
NPN (DC)
plug connector
M12 x 1
E65-SMSD200-GDD
135723
Light
switching
200
NPN (DC)
2 m connection
cable
E65-SMSD200-GL
135724
Light
switching
200
NPN (DC)
plug connector
M12 x 1
E65-SMSD200-GLD
135725
Polarized reflex
For combination
with reflector
Dark
switching
3000
NPN (DC)
2 m connection
cable
E65-SMPR3-GD
135714
Dark
switching
3000
NPN (DC)
plug connector
M12 x 1
E65-SMPR3-GDD
135715
Light
switching
3000
NPN (DC)
2 m connection
cable
E65-SMPR3-GL
135716
Light
switching
3000
NPN (DC)
plug connector
M12 x 1
E65-SMPR3-GLD
135717
Information relevant for export to North America
Product Standards
UL 508; CSA-C22.2 No. 14; IEC60947-5-2; CE marking
UL File No.
E166051
UL CCN
NRKH, NRKH7
CSA File No.
UL report applies to both Canada and US
CSA Class No.
–
NA Certification
UL Listed, certified by UL for use in Canada
Max. Voltage Rating
132 V AC, 30 V DC
Degree of Protection
IEC: IP68, IP69K; UL/CSA Type: 1, 3, 4, 4X, 6, 6P, 12, 13
Rated
operational
voltage
Function
Switching
principle
Ratedswitching
distance
S
n
Switching
type
Connection
options
Part no.
Article no.
Price
See price
list
Std. pack
mm
E65 SM Series
4-conductors, insulated material
10 - 30 V DC Reflex sensor
With background
suppression
(Perfect Prox)
Dark
switching
50
NPN
PNP
2 m connection
cable
E65-SMPP050-HD
135702
1 off
Dark
switching
50
NPN
PNP
plug connector
M12 x 1
E65-SMPP050-HDD
135703
Light
switching
50
NPN
PNP
2 m connection
cable
E65-SMPP050-HL
135704
Light
switching
50
NPN
PNP
plug connector
M12 x 1
E65-SMPP050-HLD
135705
Dark
switching
100
NPN
PNP
2 m connection
cable
E65-SMPP100-HD
135710
Dark
switching
100
NPN
PNP
plug connector
M12 x 1
E65-SMPP100-HDD
135711
Light
switching
100
NPN
PNP
2 m connection
cable
E65-SMPP100-HL
135712
Light
switching
100
NPN
PNP
plug connector
M12 x 1
E65-SMPP100-HLD
135713
HPL03102EN
