3/100 Sensors
E58 Series
2010 CA08103002Z-EN
Optical sensors
Optical sensorsE58Series
Dimensions
Technical data
Excess gain chart
Thru-beam
① Thru-beam
Reflex
② 84 mm-reflector
Polarized reflex
③ 84 mm-reflector
Perfect Prox®
① 18 mm diameter,
50 mm-designs
② 18 mm diameter,
100 mm-designs
③ 30 mm diameter,
150 mm-designs
④ 30 mm diameter,
280 mm-Design
E58 Series
E58-18...
E58-30...
2-wire 4-wire
E58-18... E58-30... E58-18... E58-30...
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -40 - +70 -25 - +55 -40 - +55 -40 - +55
Protection type IP67 IP67 IP67 IP67
Mechanical shock resistance 100
Shock duration 3 ms
Characteristic values
Rated operating voltage 18 - 50 V DC 18 - 50 V DC 10 - 30 V DC 10 - 30 V DC
Operating current in the switched state at 24 V DC Ib mA 1.7 1.7 – –
Rated operational current Ie mA 100 100 100 100
Switching frequency Hz 14 14 500 312
Switching state indication LED Red Red Red Red
Protective functions Short-circuit protection
Protection against polarity reversal
Protection against wire breakage
Function 2-wire 2-wire 4-wire 4-wire
Construction type
Design (outer dimensions) M18 x 1 M30 x 1.5 M18 x 1 M30 x 1.5
Material Stainless steel Stainless steel Stainless steel Stainless steel
Notes Further technical data can be found in the Online Catalogue at
1000
10
1
100
0.3 0.03 3.0 30.5 305
[m]
c
b a
1000
10
1
100
2.5 25 254 2540
ba c d
[mm]
80
39
o
15
40 5.5
23.8
a
a
4
M18 x 1
28
Connection cable: 6.6 feet (2 m)
Plug connector M12: 7 ±1 (178 ±25)
111
51 22
o
15
66 a
a
5
M30 x 1.5
28
Connection cable: 6.6 feet (2 m)
Plug connector M12: 7 ±1 (178 ±25)
