3/104 Sensors
E65 SM Series
2010 CA08103002Z-EN
Optical sensors
Engineering
Dimensions
Circuit diagram
E65...GD
E65...GL
E65...GDD
E65...GLD
E65...HA E65...HAD
E65...HD
E65...HL
E65...HDD
E65...HLD
Excess gain chart
① Thru-beam sensor
② Reflex sensor with polarizing filter
① 50 mm Perfect Prox®
② 100 mm Perfect Prox®
Photoelectric sensors
(90 % reflective test card)
E65 SM Series
E65...-GD E65...-HDD E65...-GDD
E65...-GL E65...-HLD E65...-GLD
E65...-HD E65...-HAD
E65...-HL
E65...-HA
BU
WH
BK
BN L1/(-)
L2/+V
N.C.
Load
L2/+V
L1/(-)
Load
NC
BU
BN
(-)
+V
(-) +V
BU
WH
(-)
BK Load
BN +V
Load (-) +V
Load
Load
0.03 0.3 3.0 30.5
10
1
100
a
b
1000
[m]
1000
10
1
100
a
b
2.5 25 254
[mm]
1000
10
1
100
2.5 25 254
[mm]
43
21
19
o 4
26
38
33
10
55
M18x1
9
27
37
15
2.5
41
a
