Position Switches
Complete units
2010 CA08103002Z-EN
LS, LSM, LSE 3/23
LS, LSM, LSECompleteunits
Complete units IP66, IP67
LS, LSM LSE11
LSE02
LSE-AI
LSE-AU
Mechanical data
Lifespan
Standard action contact Operations x 106 8 – 3
Snap-action contact Operations x 106 8 3 (electronic) –
Contact temperature of roller head °C ≦ 100 ≦ 100 ≦ 100
Mechanical shock resistance
(half-sinusoidal shock, 20 ms)
Standard action contact g 25 – –
Snap-action contact g – – –
Basic Unit g – 30 30
Operating frequency Operations/h ≦ 6000 ≦ 3000 ≦ 3000
Switching point – 0.5 - 5.5 mm,
freely adjustable
–
Hysteresis mm – 0.4 0.4
Resolution mm – 0.04 0.06
Drive
Mechanical
Actuating force at beginning/end of stroke
Basic units N 1.0/8.0 3.5/8.0 3.5/8.0
LS(M)-XP N 1.0/8.0 1.0/8.0 1.0/8.0
LS(M)-XL N 1.0/8.0 1.0/8.0 1.0/8.0
LS(M)-XLA N 1.0/8.0 1.0/8.0 1.0/8.0
Actuating torque of rotary drives Nm 0.2 0.2 0.2
Max. operating speed with DIN cam
Basic unit for angle of
actuation
α = 0°/30° m/s 1/0.5 1/0.5 1/0.5
LS(M)-XRL for angle of
actuation
α = 0° m/s 1.5 1.5 1.5
LS(M)-XRLA for angle of
actuation
α = 30°, L = 125 mm m/s 1.5 1.5 1.5
LS(M)-XRR for L = 130 mm m/s 1.5 1.5 1.5
LS(M)-XL for angle of
actuation
α = 30°/45° m/s 1 1 1
LS(M)-XLA for angle of
actuation
α = 30°/45° m/s 1 1 1
LS(M)-XP for angle of
actuation
α = 0°/30° m/s 1/1 1/1 1/1
Electromagnetic compatibility (EMC)
Electrostatic discharge (ESD), to IEC EN 61000-4-2
Air discharge kV – 8 8
Contact discharge kV – 4 4
Electromagnetic fields (RFI), to IEC EN 61000-4-2 V/m – 10 10
Burst, to IEC/EN 61000-4-4
Supply cables kV – 2 2
Signal cables kV – 2 2
High-energy pulses (surge) (IEC/EN 61000-4-5) kV – 0.5 0.5
Radiated RFI, to IEC/EN 61000-4-6 V – 10 10
Notes Accessories for the Cage Clamp terminals from Wago:
Power comb, gray, Wago Article No. 264-402
plug connectors
M12A(B) M12A(B)
General
Pole 4 5
Protection type IP66 IP66
Lifespan, mechanical Operations > 500 > 500
Characteristic values
Rated operating voltage Ue V AC 250 125
Rated operational current Ie A 1 1
Overvoltage category/pollution degree II/3 II/3
