3/18 Position Switches
Safety position switches
2010 CA08103002Z-EN
www.eaton.comLSR, LS...ZB
LSR, LS...ZBSafetyposition switches
Contact configuration
Circuit
symbol
Contact travel
■= Contact closed
□ = Contact open
Approval mark
Connection
type
Part no.
Article no.
Price
See
price list
Std. pack
Positive opening safety
function according to
IEC/EN 60947-5-1
N/O = normally
open contact
NC = normally
closed contact
Hasp-operated safety switch LSR-…/TKG, IP65
–
2 NC
Screwed
terminal
LSR-S02-1-I/TKG
106848
1 off
1 N/O
1 NC
Screwed
terminal
LSR-S11-1-I/TKG
106847
1 off
Hinge-operated switch LSR-…/TS, IP65
–
2 NC
Screwed
terminal
LSR-S02-1-I/TS
106852
1 off
1 N/O
1 NC
Screwed
terminal
LSR-S11-1-I/TS
106851
1 off
Safety position switches LS-…-ZB, IP65
–
2 NC
Cage
Clamp
LS-02-ZB
1)
106817
2 off
–
2 NC
Screwed
terminal
LS-S02-ZB
1)
106874
2 off
1 N/O
1 NC
Cage
Clamp
LS-11-ZB
1)
106819
2 off
1 N/O
1 NC
Screwed
terminal
LS-S11-ZB
1)
106876
2 off
1 N/O
1 NC
Cage
Clamp
LS-11S-ZB
1)
106870
2 off
1 N/O
1 NC
Screwed
terminal
LS-S11S-ZB
1)
106877
2 off
Safety position switches LS4…/ZB, IP65
1 N/O
1 NC
Screwed
terminal
LS4/S11-1/I/ZB
2)
106857
1 off
1 N/O
1 NC
Screwed
terminal
LS4/S11-1/IA/ZB
2)
106858
1 off
1 N/O
2 NC
Screwed
terminal
LS4/S12-7/IB/ZB
2)
106859
1 off
Notes
Electric circuitry with
contactors DIL and safety
relay ESR5
￫Safety manual
TB02000-009,
Article no. 119906
1)
2)
Actuator can be repositioned for horizontal or
vertical installation. The operating heads can
be rotated manually in 90° steps to suit the
specified level of actuation.
Information relevant for export to North America
Product Standards IEC/EN 60947-5;
UL 508; CSA-C22.2 No. 14;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
12528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA Certified
Degree of Protection IEC: IP65, UL/CSA Type 3R,
4X (indoor use only), 12, 13
Switch must never
be used as a
mechanical stop!
For protection type IP65 use
cable glands V-M20 with
max. 9 mm connection
thread length.
Cable gland V-M20
￫Page 2/46
With the actuator inserted,
the N/O contact is open and
the NC contact is closed.
12 22
21 11
21– 22
11– 12
90
°
Zw= 10
°
5
°
5
°
0
°
90
°
14 22
21
13
21– 22
13– 14
90
°
Zw= 10
°
5
°
5
°
0
°
90
°
17
°
17
°
12 22
21 11
21– 22
11– 12
180
°
Zw= 10
°
5
°
5
°
0
°
180
°
14 22
21
13
21– 22
13– 14
180
°
Zw= 10
°
5
°
5
°
0
°
180
°
17
°
17
°
22
21 11
12
13
14 22
21
13
14 22
21
13-14
21-22
Zw= 3.9mm
2.65 3.55
0
6.0
13
14 22
21
13-14
21-22
Zw= 3.9mm
2.65 3.55
0
6.0
13
14 22
21 31
32
13-14
21-22
31-32
Zw= 3.9mm
2.6 3.6
0
6.05
