3/22 Position Switches

Complete units

2010 CA08103002Z-EN

LS, LSM, LSE

LS, LSM, LSE

Completeunits

Technical data

Complete units IP66, IP67

LS, LSM

LSE11

LSE02

LSE-AI

LSE-AU

General

Standards

IEC/EN 60947

IEC/EN 60947

EN 61000-4

IEC/EN 60947

EN 61000-4

IEC/EN 60947

EN 61000-4

Climatic proofing

Damp heat, constant, to IEC 60068-2-78,

Damp heat, cyclic, to IEC 60068-2-30

Ambient temperature

°C

-25 - +70

-25 - +70

-25 - +70

-25 - +70

Mounting position

Any

Any

Any

Any

Protection type

IP66, IP67

IP66, IP67

IP66, IP67

IP66, IP67

Terminal capacity of screw terminal and Cage Clamp

Solid

mm

2

1 x (0.5 - 2.5)

1 x (0.5 - 2.5)

1 x (0.5 - 2.5)

1 x (0.5 - 2.5)

Flexible with ferrule to DIN 46228

mm

2

1 x (0.5 - 1.5)

1 x (0.5 - 1.5)

1 x (0.5 - 1.5)

1 x (0.5 - 1.5)

Power supply

Rated voltage

U

e

V DC

–

12…30

24 (-15…+20 %)

24 (-15…+20 %)

Rated operational current

12 V

I

e

mA

–

15

–

–

24 V

I

mA

–

18

28…45

24

30 V

I

mA

–

19

–

–

Contacts/switching capacity

Rated impulse withstand voltage

U

imp

V AC

4000

–

–

–

Rated insulation voltage

U

i

V

400

–

–

–

Overvoltage category/pollution degree

III/3

III/3

–

–

Rated operational current

AC-15

24 V

I

e

A

6

–

–

–

230 V/240 V

I

e

A

6

–

–

–

400 V/415 V

I

e

A

4

–

–

–

DC-13

24 V

I

e

A

3

0.2

–

–

110 V

I

e

A

0.8

–

–

–

220 V

I

e

A

0.3

–

–

–

Analog output Q1

Output voltage (max. 10 mA)

V DC

–

–

–

0…10

Output current

mA

–

–

4 - 20

–

Fault scenario

V

–

–

0

0

Resolution

Steps

–

–

100

100

Step tolerance

Steps

–

–

<1

<1

Shunt resistor, resistive load

Ω

–

–

< 400

> 1000

Digital diagnostics output Q2

(positive switching PNP)

Response threshold

V

–

–

approx. U

e

approx. U

e

mA

–

–

< 200

< 200

Fault scenario

V

–

–

0

0

Control circuit reliability

At 24 V DC/5 mA

H

F

Fault

frequency

< 10

-7

, < 1 fault in

10

7

operations

–

–

–

At 5 V DC/1 mA

H

F

Fault

frequency

< 10

-6

, < 1 fault in

5 x 10

6

operations

–

–

–

Mains frequency

Hz

max. 400

–

–

–

Short-circuit rating to IEC/EN 60947-5-1

Max. fuse

A gG/gL

6

–

–

–

Repetition accuracy

mm

± 0.02

± 0.02

± 0.02

± 0.02

UL-File No. E29184

Rating data for approved types to UL/CSA

Pilot Duty

AC operated

A300

–

–

–

DC operated

Q300 (1 A, 250 V DC)

Q300 (0.2 A, 24 V DC)

–

–

UL-approved degrees of protection

NEMA 4, 12, 13

NEMA 4, 12, 13

NEMA 4, 12, 13

NEMA 4, 12, 13
