3/24 Position Switches
Safety position switches
2010 CA08103002Z-EN
www.eaton.comLS-...ZB
LS-...ZBSafety position switches
(Safety)position switchesLS-Titan
Safety position switches
LS-…ZBZ
LS-…ZB
LS4…ZB
LSR...
General
Standards
IEC/EN 60947
IEC/EN 60947
IEC/EN 60947
IEC/EN 60947
Climatic proofing
Damp heat, constant, to IEC 60068-2-78,
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
°C
-25 - +40
-25 - +70
-25 - +70
-25 - +70
Mounting position
Any
Any
Any
Any
Protection type
IP65
IP65
IP65
IP65
Terminal capacity
Solid
mm
2
1 x (0.75 - 2.5)
2 x (0.75 - 1.5)
1 x (0.5 - 1.5)
2 x (0.5 - 1.5)
1 x (0.75 - 2.5)
2 x (0.75 - 1.5)
1 x (0.75 - 2.5)
2 x (0.75 - 1.5)
Flexible with ferrule to DIN 46228
mm
2
1 x (0.5 - 1.5)
2 x (0.5 - 1.5)
1 x (0.5 - 1.5)
2 x (0.5 - 1.5)
1 x (0.5 - 1.5)
2 x (0.5 - 1.5)
1 x (0.5 - 1.5)
2 x (0.5 - 1.5)
Terminal screw
PH1
PH1
PH1
PH1
Terminal screw tightening torque
Nm 0.9
0.4
0.9
0.9
Contacts/switching capacity
Rated impulse withstand voltage
U
imp
V AC
4000
6000
6000
6000
Rated insulation voltage
U
i
V
400
500
500
500
Overvoltage category/pollution degree
III/3
III/3
III/3
III/3
Rated operational current
AC-15
24 V
I
e
A
6
6
10
10
230 V/240 V
I
e
A
6
6
6
6
400 V/415 V
I
e
A
4
4
4
4
DC-13
24 V
I
e
A
3
3
3
3
110 V
I
e
A
0.8
0.8
0.8
1
220 V
I
e
A
0.3
0.3
0.3
0.5
Mains frequency
Hz
max. 400
max. 400
max. 400
max. 400
Short-circuit rating to IEC/EN 60947-5-1
Max. fuse
A gG/gL 6
6
6
6
Repetition accuracy
mm ± 0.02
± 0.02
± 0.02
± 0.02
Mechanical data
Lifespan
Standard action contact
Operations
x 10
6
1
10
10
20
Snap-action contact
Operations
x 10
6
–
–
–
20
Mechanical shock resistance
(half-sinusoidal shock, 20 ms)
Standard action contact
g
10
25
5
25
Snap-action contact
g
–
2
–
2
Operating frequency
Operations/h
≦ 800
≦ 1800
≦ 1800
≦ 1800
Drive
Mechanical
Actuating force at beginning/end of stroke
ZB/ZBZ (push-in/pull-out)
N
25/15
10/5
15/20
Mechanical holding force acc. to GS-ET-19 (04/2004)
XG, XW, XNG
N
1700
–
–
XWA, XFG, XF
N
1600
–
–
XNW
N
1200
–
–
Electro mechanical
For magnet
Power consumption
At 120 V AC
VA
8
–
–
At 230 V AC
VA
11
–
–
At 24 V DC
W 8
–
–
Voltage tolerance
x U
s
0.85 - 1.1
Magnet duty factor
% DF
100
–
–
UL-File No. E29184
Rating data for approved types to UL/CSA 1)
General Use
AC operated
V
300
–
–
AC operated
A
10
–
–
Pilot Duty
AC operated
A300
A300
A300
DC operated
Q300
Q300
(1 A, 250 V DC)
Q300
UL-approved degrees of protection
NEMA 4, 12, 13
NEMA 12, 13
–
