Position Switches
Contact travel diagrams
2010 CA08103002Z-EN
LSE 3/19
LSEContact traveldiagramsEngineering
LSE-11 LSE-02
Basic units
Operating heads
Roller plunger
LS-XP
LSM-XP
LS-XOR
Roller lever
LS-XL
LSM-XL
LS-XLS
LS-XLB
Angled roller lever
LS-XLA
LSM-XLA
Rotary lever
LS-XRL
LSM-XRL
Adjustable roller lever
LS-XRLA
LSM-XRLA
LS-XRLA30
LS-XRLA40
LS-XRLA40R
Actuating rod
LS-XRR
LSM-XRR
LS-XRRM
LSM-XRRM
Spring rod actuator
LS-XS
LSM-XS
Q2 Q1 Q2 Q1
Q1
Q2
0.5 5.5
default=3.0
6.1 0
Q1
Q2
0.5 5.5
default=3.0
6.1 0
Q1
Q2
0.5 5.5
default=3.0
6.1 0
Q1
Q2
0.5 5.5
default=3.0
6.1 0
Q1
Q2
0.5 9.0
default=4.4
9.6 0
Q1
Q2
0.5 9.0
default=4.4
9.6 0
Q1
Q2
0.5 10
default=5.0
10.8 0
Q1
Q2
0.5 10
default=5.0
10.8 0
Q1
Q2
5˚ 60˚
default=30˚
65˚ 0˚
Q1
Q2
5˚ 60˚
default=30˚
65˚ 0˚
Q1
Q2
5˚ 60˚
default=30˚
65˚ 0˚
Q1
Q2
5˚ 60˚
default=30˚
65˚ 0˚
Q1
Q2
5˚ 60˚
default=30˚
65˚ 0˚
Q1
Q2
5˚ 60˚
default=30˚
65˚ 0˚
Q1
Q2
3˚ 23˚
default=13˚
26˚ 0˚
Q1
Q2
3˚ 23˚
default=13˚
26˚ 0˚
