3/14 Position Switches LS...ZBZ, LS...ZB, LSR...
2010 CA08103002Z-EN
LS...ZBZ,LS...ZB, LSR...
LS-...ZB LS4/ZB LSR-...TKG LSR-...TS
“Personnel protection” by monitoring of the protective mechanism
• Door open
• LS...-ZB disconnects power
• No danger
STOP
LS/ZBZ
“Increased personnel protection” by monitoring and interlocking the protective mechanism
• Stop command
• Waiting time
• Machine is stopped
• Protective mechanism open
• No danger
STOP
LS/ZBZ
“Increased personnel protection” by monitoring and interlocking the protective mechanism
• Stop command
• Waiting time
• Process sequence halted
• Protective mechanism open
• Product OK STOP
