Position Switches LS...ZB(Z), LSR
LS-...ZBZ
Basic Unit 1
Spring or magnet-powered interlock
For increased personnel and process
protection
Tamper-proof
Multiple coded actuators
Contact configuration: 1 N/O / 1 NC or 2
NC
￫Page 3/16
Flat flexible actuator 2
For doors that do not close precisely
￫Page 3/17
Angled flexible actuator 3
For doors that do not close precisely
￫Page 3/17
Flat actuator 4
For sliding doors
￫Page 3/17
Angled actuator 5
For swing doors
￫Page 3/17
Flat compensating actuator 6
For increased tolerance compensation
in the direction of door closure
￫Page 3/17
Angled compensating actuator 7
For increased tolerance compensation
in the direction of door closure
￫Page 3/17
LS-...ZB
Complete unit 1
For personnel protection
Contact configuration: 1 NC,
1 N/O / 1 NC or 2 NC
5 directions of operation possible
￫Page 3/18
Actuator 2
Multiple coding protection against
tampering
LSR-...TKG, LSR-…TS
Complete unit 1
For personnel protection
Contact configuration: 1 N/O / 1 NC or 2
NC
For swing doors with fixed connection to
the door/hinge pin
Multiple coded actuators
Contact configuration: 1 N/O / 1 NC or 2
NC
LSR-…TKG￫Page 3/18
LSR-…TS￫Page 3/18
LS4.../ZB
Complete unit 1 Actuator 2
Narrow enclosure version Multiple coding
For personnel protection For horizontal or vertical operation
Contact configuration: 1 NC,
1 N/O / 1 NC
￫Page 3/16
Product features
Interlocking unit to EN 1088
• For use in safety circuits
• Positive opening safety function
according to IEC/EN 60947-5-1
• Protection type IP65
• Operating head can be turned
4 x 90°
• With M20 x 1.5 connecting thread
