123 / 336
3/10 Position Switches
Accessories
2010 CA08103002Z-EN
www.eaton.comLS-Titan
LS-TitanAccessories
Notes
Description
Part no.
Article no.
Price
See price
list
Std. pack
Notes
Information relevant for export to
North America
Screw connection to fit M20 to ½"
Screw connector for American
pipe thread
Metal
V1/2"/M20-NA
225269
10 off
The screw connec-
tion is for grounding;
no total insulation
For connection
thread lengths
up to 9 mm
Product Standards UL 508;
CSA-C22.2
No. 14
UL File No.
E29184
UL CCN
NKCR
CSA File No.
12528
CSA Class No.
3211-03
NA Certification
UL Listed,
CSA
Certified
Specially designed for NA✓
Screw connector for American
pipe thread
Molded material
V1/2"/M20
225270
10 off
For connection
thread lengths
up to 9 mm
UL/CSA certification not required
M20 diaphragm bolt, IP65
With built in push-through
diaphragm
External diameter of cable
up to 13 mm
IP65 with cable inserted
EMS20
225271
25 off
–
Screw closure M20
(self-sealing grommet)
For tightening/loosening using a
standard spanner for sealing
grommet plugs
LS-X20
266134
25 off
–
Plug connector M12x1, IP66
Molded material
I
th
= 4 A
Fuse: 6 A gG/gL
4-pole
U
e
= 250 V
For use with
LS
“A” coded
Standard to
IEC/EN 60947-5-2
M12A
266135
10 off
LS
“B”-coded
M12B
266136
10 off
5-pole
U
e
= 125 V
LSM
“A” coded
Standard to
IEC/EN 60947-5-2
M12A5
272202
10 off
LSM
“B”-coded
M12B5
272203
10 off
Cage clamp twin NC contacts
–
For opening
two terminals
simultaneously
LS-XTW
290179
1 off
–
UL/CSA certification not required
Adapter plate, thickness 2.5 mm
For additional fixing with
sideways operation, together
with locating plate FS-AT
(order separately)
LS-XAP
114026
1 off
Locating plate
For fixing with side motion
FS-AT
019610
20 off
–
M20
1/2"
1/2"
M20
1
2
1
2
3
4
B
4
2
1
3
..-11-.. ..-20-..
1
2
3
4
..-02-..
A
4
2
1
3
3
4
M12A, M12B
1
2
1
2
3
4
B
4
2
1
3
..-11-.. ..-20-..
1
2
3
4
..-02-..
M12A5, M12B5
A
4
2
1
3
3
4
HPL030010EN
