Darwin Technology
SWD contactor modules, SWD PKE module
2010 CA08103002Z-EN
1/13
SWDcontactormodules,SWDPKEmoduleFeatures
MSC-DEA networkable PKE-based
motor starter ￫Chapter 8
• Plug & play-capable motor starter
combi-nationupto15kW,consistingof
PKE basic unit, contactor DILM and
PKE trip block PKE-XTUA.
• Exchangeable trip blocks for cover of
current ranges.
• Wide-range overload protection
ratio 4:1.
• Adjustable time-lag classes
(CLASS 5, 10, 15, 20) for different
tripping characteristics.
• Networkable via SWD PKE module.
Powerfeed module ￫Page 1/6
• Provision of SmartWire-Darwin supply
voltage.
• Provision of 24 V DC supply voltage for
activating the contactors.
• Formation of emergency-stop groups.
SWD PKE module￫Page 1/14
• Pluggable onto contactors in the
xStart range.
• Suitable for motor starters MSC-DEA-
…(24V DC) or DILM(C)7 -DILM(C)32 in
combination with PKE12/32 and trip
block PKE-XTUA-…
• Use of the standard switchgear of the
xStart range.
• Use of the standard accessories in the
xStart range.
• Integrated mechanical contactor
switching state indication.
• Integrated contactor switching state
scanning.
• Transmission of PKE-specific data
(switch position PKE, relative motor
current, thermal motor image, trip indi-
cations (overload, short-circuit,…),
type PKE trip block, set value of over-
load release and time-lag class).
• Communication cable (PKE32-COM)
for connection to PKE trip block
included as standard.
• Contactor actuation.
• Selectable ZMR functionality
(contactor opening on overload).
• SWD diagnostics LED for signalling
the communication status of the
modules and signalling of the switch
command via SmartWire-Darwin.
• Manual/Auto functionality for
automatic or manual switching on
of the connected contactor.
• Connection to SmartWire-Darwin
ribbon cable via device plug.
SWD contactor module ￫Page 1/14
• Pluggable onto contactors in the
xStart range.
• Suitable for contactors DILM7 DILM38
(24VDC), DILMC7…DILMC32 (24 VDC),
DILA DILMP20 DILMP45 (24 VDC
RDC24) or motor starter MSC-
…(24 VDC).
• Use of the standard switchgear of the
xStart range.
• Use of the standard accessories in the
xStart range.
• Suitable for contactor combinations
with PKZ or with Z overload relays.
• Integrated switch position scanning.
• Integratedmechanical switch position
indication.
• Contactor actuation.
• SWD diagnostics LED for signalling
the communication status of the
modules and signalling of the switch
command via SmartWire-Darwin.
• Two digital inputs for scanning floating
contacts, such as motor-protective
circuit-breaker auxiliary contacts.
• For DIL-SWD-32-002 built-in Manual/
Auto functionality for automatic or
manual switching on of the connected
contactor.
• Connection to SmartWire-Darwin
ribbon cable via device plug.
SWD input/output modules￫Page 1/6
• Digital module with four 24 V DC digital
inputs and two relay outputs for
actuating contactors DILM40-DILM72.
• Connection to SmartWire-Darwin
through device plug.
Link for device plug ￫Page 1/17
• Connection to SmartWire-Darwin
device plug.
• Suitable for the bridging of already
adapted device plugs (e.g. as a
placeholder).
Planning and ordering help (SWD assist)
• Easy generation of applications with
the SmartWire-Darwin system.
• Integrated function for the generation
of ordering lists.
• Integrated plausibility check.
• Online functionality.
– Simple preliminary commissioning
of SmartWire-Darwin inputs and
outputs and function testing.
– Simple diagnostics of SmartWire-
Darwin slaves.
• Free download under
Safety engineering
• Emergency-stop disconnection
to IEC/EN 954-1, switching category 3;
EN ISO 13849-1 PL d; IEC 62061 SIL 2
• Central switch off of the control
voltage at the gateway or power
feeder module.
• Combination with safety-related
switchgears possible.
Design note
“The number of motor starters or DILM contactors that can be connected is dependent upon the power consumption of the magnet systems per SmartWire Darwin line.
To increase the number of SmartWire-Darwin modules that can be connected power feeder modules can be used.”
24 V DC DILM(C)7, DILA DILM(C)9 DILM(C)12,
DILMP20
DILM(C)15 DILM(C)17 DILM(C)25 DILM(C)32,
DILMP32
DILM38,
DILMP45
Pick-up power
[W] 3 3 4.5 4.5 12 12 12 12
Holding power
[W] 3 3 4.5 4.5 0.5 0.5 0.5 05
