1/12 Darwin Technology
SWD contactor modules, SWD PKE module
2010 CA08103002Z-EN
System overview
SWD-AssistV1.00
DarwinTechnology
Planning tool for theSmartWire-Darwin
product range
9
4 10
16
4
14 15
3
8
2
1
7
2 1
3
4 5
6
13
11
12
10
4
MSC-DEA networkable PKE-
based motor starters up to
7 kW￫ Features
1
MSC-D DOL starters based
on PKZM0 up to 7 kW
￫Chapter 8
2
MSC-R reversing starters
based on PKZM0 up to 7 kW
￫Chapter 8
3
SWD ribbon cable
￫Page 1/17
4
Network terminator
￫Page 1/17
5
Planning and ordering help,
SWD assist ￫ Features
6
MSC-DEA networkable PKE-
based motor starters up to
15kW￫ Features
7
MSC-D DOL starters based
on PKZM0 up to 15 kW
￫Chapter 8
8
MSC-R reversing starters
based on PKZM0 up
to 15 kW￫Chapter 8
9
SWD device plug
￫Page 1/17
10
Power feeder module
￫ Features
11
SWD input/output module
with relay outputs
￫ Features
12
Modules SWD PKE modules
￫ Features
13
SWD contactor module with
manual/auto functionality
￫ Features
14
SWD contactor module
￫ Features
15
Link for device plug
￫Page 1/17
16
