SWD RMQ connections
2010 CA08103002Z-EN
1/9
SWDRMQconnections
RMQ-Titan, 4-way selector
switch￫Chapter 2
1
RMQ-Titan, label with label
mount for 4-way selector
switch and joystick
￫Chapter 2
2
SWD front mounting adapter
for 2 × M22-SWD-K22
￫Page 1/11
3
RMQ-Titan, front mounting
adapter with three mounting
locations ￫Page 1/11
4
SWD function element
with 3 positions for front
mounting￫ Features
5
SWD LED element for front
mounting￫ Features
6
SWD function element
with 2 positions for front
mounting￫ Features
7
SWD function element with
2 positions and LED for front
mounting￫ Features
8
SWD function element with
3 positions and LED for front
mounting￫ Features
9
Link for SWD device plugs
￫ Features
10
Features
SWD-RMQ connection for front
fixing￫Page 1/10
• Adaptation with standard adapter
M22-A or M22-SWD-A4 for 4-way
selector switch/pushbutton and
joystick.
• Combination with standard pilot
devices of the RMQ-Titan M22
serie.
• Types with one or two change over
contacts and with/without
integrated LED element.
• LED elements in four colors.
• SmartWire-Darwin diagnostics
LED for signalling of the communi-
cation status of the function
element.
• Connection to SmartWire-Darwin
ribbon cable with device plug.
.
RMQ-Titan, M22 contact
elements for front mounting
￫Chapter 2
11
SWD device plug
￫Page 1/17
12
SWD ribbon cable
￫Page 1/17
13
SWD-Assist, Planning and
ordering help￫ Features
14
RMQ-Titan, surface
mounting enclosure
￫Chapter 2
15
SWD PCB for surface
mounting enclosure
￫ Features
16
Cable gland for SWD round
cable￫Chapter 2
17
SWD bulkhead plug/socket
RJ45 with prefabricated
signal cables ￫ Features
18
SWD socket/plug for round
cable￫ Features
19
SWD round cable
￫Page 1/18
20
Link for device plug
￫Page 1/11
• Connection to SmartWire-Darwin
device plug.
• Suitable for bridging adapted
external SmartWire-Darwin device
plugs (e.g. as placeholders).
Surface mounting enclosure with
PCB￫Page 1/11
• Connection of SmartWire-Darwin
function elements for base fixing.
• Type with 1, 2, 3, 4 and 6 slots.
• Bridging of free slots with link for
base fixing.
• Integrated connectable network
terminator.
RMQ-Titan, M22 contact
elements with base fixing
￫Chapter 2
21
Link for SWD PCB
￫Page 1/11
22
SWD function element with
3 positions and LED for base
fixing￫ Features
23
SWD function element with
3 positions for base fixing
￫ Features
24
SWD function element with
2 positions and LED for base
fixing￫ Features
25
SWD function element with
2 positions for base fixing
￫ Features
26
SWD LED element for base
fixing￫ Features
27
RMQ-Titan, bezels
￫Chapter 2
28
RMQ-Titan, double
actuators ￫Chapter 2
29
SWD RMQ connection for base fixing
￫Page 1/10
• For use with SWD PCB, RMQ-Titan
surface mounting enclosure and
RMQ-Titan M22 control circuit
devices.
• Types with one or two change over
contacts and with/without
integrated LED element.
• LED elements in four colors.
• SmartWire-Darwin diagnostics
LED for signalling of the communi-
cation status of the function
element.
Housing bushing socket
￫ Page 1/18
• Use for RMQ-Titan M22 surface
mounting enclosure or control
panel.
• Type plug/socket.
• Prefabricated signal cable with
ferrules for connection to PCB for
surface mounting enclosure.
RMQ-Titan, insert labels
￫Chapter 2
30
RMQ-Titan, label mount
for double actuator push-
buttons ￫Chapter 2
31
RMQ-Titan, indicator light
￫Chapter 2
32
RMQ-Titan, key-operated
actuator ￫Chapter 2
33
RMQ-Titan, selector switch
actuator ￫Chapter 2
34
RMQ-Titan, button plates/
button lenses ￫Chapter 2
35
RMQ-Titan, pushbutton
actuators ￫Chapter 2
36
RMQ-Titan, label mounts
￫Chapter 2
37
RMQ-Titan, emergency stop
pushbuttons (for safety
circuits use only standard
contacts M22) ￫Chapter 2
38
RMQ-Titan, joystick
￫Chapter 2
39
RMQ-Titan, 4-way
pushbutton￫Chapter 2
40
Planning and ordering help
(SWD Assist)
• Easy generation of applications
with the SmartWire-Darwin
system.
• Integrated function for the
generation of ordering lists.
• Integrated plausibility check.
• Online functionality:
– Simple preliminary commission-
ing of SmartWire-Darwin inputs
and outputs and function testing.
– Easy diagnostics of SmartWire-
Darwin slaves.
• Free download under
