Darwin Technology
Gateways, I/O modules, power feed modules
2010 CA08103002Z-EN
1/5
Gateways, I/Omodules,power feedmodules
Sub-D data plug, 9 pole 1
SmartWire-Darwin
gateways
2
SmartWire-Darwin
blade terminal 8 pole
3
SmartWire-Darwin
ribbon cable, 8 pole
4
SmartWire-Darwin
input/output modules
5
SmartWire-Darwin
device plug 8 pole
6
SmartWire-Darwin
connection for NZM
7
NZM circuit-breakers 8
Features
SmartWire-Darwin gateway
• Connection of SmartWire-Darwin
to fieldbus.
• Supports the PROFIBUS-DP and
CANopen fieldbuses.
• Provides of the supply voltage for
the SmartWire-Darwin slaves.
• Supplies the control voltage for the
motor starters or contactors.
• Configuration button for automatic
addressing of the SmartWire-
Darwin slaves.
• Support of up to 99 SmartWire-
Darwin slaves.
• Connection of the SmartWire-
Darwin ribbon cable via blade
terminal.
SmartWire-Darwin
contactor module
9
DILM contactors 10
SmartWire-Darwin
contactor module with
Manual-0-Automatic switch
11
Motor protective circuit
breakers
12
MSC motor starters 13
SmartWire-Darwin
PKE modules
14
PKE motor starters with
electronic motor protection
15
DS7 soft starter with PKE
electronic motor protection
16
SmartWire-Darwin
input/output module
• Connection to SmartWire-Darwin
ribbon cable via device plug.
• Integration of other switching
devices without integrated Smart-
Wire-Darwin technology.
• Variant with 8 digital inputs, or
4 digital inputs and 4 non-isolated
transistor outputs, or 4 digital
inputs and 2 relay outputs 250 V AC.
• SmartWire-Darwin diagnostics
LED for signalling of the communi-
cation status of the module.
SmartWire-Darwin
powerfeed module
17
SmartWire-Darwin
LED elements,
front fixing
18
RMQ-Titan mounting
adapter for front mounting
19
RMQ-Titan indicator light 20
SmartWire-Darwin
function elements for
front fixing
21
SmartWire-Darwin
operating elements
22
SmartWire-Darwin
control panel cable adapter
for flat to round cable
23
SmartWire-Darwin
plug connectors
24
Power feeder module
• Connection to SmartWire-Darwin
ribbon cable via blade terminal.
• Provides of the supply voltage for
the SmartWire-Darwin slaves.
• Control voltage feeder for the
motor starters and contactors.
• Formation of emergency-stop
groups.
RMQ-Titan surface
mounting enclosure
25
SmartWire-Darwin
card for function elements,
base fixing
26
SmartWire-Darwin
LED elements for base fixing
27
SmartWire-Darwin
Function elements for base
fixing
28
SmartWire-Darwin
adapter for flat/round
cable for top-hat rail
mounting
29
SmartWire-Darwin
network termination for
8 pole ribbon cable
30
DS7 soft starters 31
SmartWire-Darwin
planning and ordering aid,
SWD-Assist
32
SmartWire-Darwin
round cable, 8 pole
33
Planning and ordering help
(SWD-Assist)
• Easy generation of applications
with the SmartWire-Darwin
system.
• Integrated function for the
generation of ordering lists.
• Integrated plausibility check.
• Online functionality
– Simple preliminary commission-
ing of SmartWire-Darwin inputs
and outputs and function testing.
– Easy diagnostics of SmartWire-
Darwin slaves
• .
• Free download under
