Darwin Technology
Gateways, I/O modules, power feed modules
2010
CA08103002Z-EN
www.eaton.comOrdering
Description
Part no.
Article no.
Price
See price list
Std. pack
SWD gateways
Gateway to the connection to the fieldbus and for supplying the SmartWire-Darwin (SWD) slaves and switchgear.
Connection to PROFIBUS-DP as slave.
Automatic baud rate detection from 9.6 kBit/s to 12 Mbit/s.
Address range 1 - 126.
9
pole SUB-D socket.
Connection of up to 58 SWD slaves.
EU5C-SWD-DP
116308
1
off
Connection to CANopen as slave.
Automatic baud rate detection from 10 kBit/s to 1 Mbit/s.
Address range 1 - 32.
9
pole SUB-D plug.
Connection of up to 99 SWD slaves.
EU5C-SWD-CAN
116307
1
off
SWD I/O modules
SmartWire-Darwin slaves for the connection of digital I/O signals.
Digital module with 8 digital inputs 24 V DC
EU5E-SWD-8DX
116381
1
off
Digital module with 4 digital inputs 24 V DC and 4 transistor outputs 24 V DC/0.5 A
EU5E-SWD-4D4D
116382
Digital module with 4 digital inputs 24 V DC and 2 relay outputs 250 V AC
EU5E-SWD-4D2R
116383
SWD powerfeed module
For additional control voltage supply of the motor starters and contactors.
For the formation of emergency-stop groups for the motor starters and contactors.
EU5C-SWD-PF1-1
116309
1
off
For the supply of other SWD slaves.
For additional control voltage supply of the motor starters and contactors.
For the formation of emergency-stop groups for the motor starters and contactors.
EU5C-SWD-PF2-1
116380
1
off
Information relevant for export to North America
NA Certification Request filed for UL and CSA
UL/CSA approval applied for
HPL01006EN
