9 / 20
POWERSTAR 125
SE L ECT I ON GU I DE
7
POWERSTAR 125 SELECTION GUIDE
l
17
GG12DR
Door Kit with catch
12
module
17
GG12MW
Cableway
12
module
17
GG03MW
Cableway
3
module
17
GG24SS
Control Module Enclosure
3
module
17
GG2506SW
6
way 250A Panelboard
with Switching unit
12
module
17
GG250INCTM
Incomer Integral
Meter Pack
17
GG4WCT125M
Outgoing Meter Pack
(
requires one voltage supply
cable loom per bank of meters)
7
T225/OR3 250A
Overcurrent Release
An appropriate overcurrent release or switch disconnector module must be selected for Panelboards which include switching units (suffixed SW)
Overall Panelboard doors are available up to 15 mod. Two doors can be used for larger units. (250A incoming section = 7 mod. 400A incoming section = 9 mod.)
Each bank of outgoing meter packs to be installed in conjunction with a voltage supply cable loom (17OUMKCL)
Product list numbers and descriptions can be found within the body of the catalogue
Modular
250
A with
250
A direct
400
A with
400
A direct
Door Kits
Height switching unit
connection switching unit
connection with catch Cableways
3
-
-
-
-
17
GG03DR 17GG03MW
5
-
-
-
-
17
GG05DR
-
6
-
-
-
-
17
GG06DR
-
7
-
-
-
-
17
GG07DR
-
8
-
-
-
-
17
GG08DR
-
9
-
-
-
-
17
GG09DR
-
10
-
-
-
-
17
GG10DR
-
12
17
GG2506SW 17GG2506DC
-
-
17
GG12DR 17GG12MW
13
17
GG2508SW 17GG2508DC
-
-
17
GG13DR 17GG13MW
14
-
-
17
GG4006SW 17GG4006DC 17GG14DR 17GG14MW
15
17
GG2512SW 17GG2512DC 17GG4008SW 17GG4008DC 17GG15DR 17GG15MW
17
17
GG2516SW 17GG2516DC 17GG4012SW 17GG4012DC
-
17
GG17MW
19
-
-
17
GG4016SW 17GG4016DC
-
17
GG19MW
Add-on Boxes
MCCB Housing
17
GG125GGMB
Incomer Meter Packs
17
GG—0MPKIT
SP&N Distribution Board
17
GG19DB
Control Module Enclosure
17
GG24SS
Cable Spreader Box
17
GGCSB
