4 / 20
250
A PANELBOARD WITH DIRECT CONNECTION
l
Inc. Terminals Outgoing Modular Height
only ways Height (mm) LIST No
250
A
6 12 912
17
GG2506DC
8 13 988
17
GG2508DC
12 15 1140
17
GG2512DC
16 17 1292
17
GG2516DC
• 250
A rated Panelboards
•
Busbar 25kA conditional
•
IP3X (door closed)
• 150
mm
2
4
Core Maximum on Incoming Terminals
•
BS EN/IEC 61439-2: 2009
OVERCURRENT RELEASE AND SWITCH
DISCONNECTOR MODULES
l
Rated Current (
I
n) Overcurrent adjustment (0.4 to 1x
I
n) LIST No
160
A
63
A .... 160A
7
T216/OR3
250
A
100
A .... 250A
7
T225/OR3
•
Adjustable overcurrent release
•
Adjustable short circuit release
250
A
Switch Disconnector
7
T225/SD
2
DIMENSIONS 250A PANELBOARDS
l
17
GG2506SW
7
T225/OR3
17
GG2506DC
630
188
532 (7
Mod)
LIST No Overall Height
Mod. Height (mm)
17
GG2506SW
12 912
17
GG2508SW
13 988
17
GG2512SW
15 1140
17
GG2516SW
17 1292
17
GG2506DC
12 912
17
GG2508DC
13 988
17
GG2512DC
15 1140
17
GG2516DC
17 1292
250
A PANELBOARD WITH TP SWITCHING UNIT
l
Outgoing Modular Height
ways Height (mm) LIST No
250
A
6 12 912
17
GG2506SW
8 13 988
17
GG2508SW
12 15 1140
17
GG2512SW
16 17 1292
17
GG2516SW
• 250
A rated Panelboards
•
Busbar 25kA conditional
•
IP3X (door closed)
• 150
mm
2
4
Core Maximum on Incoming Terminals
•
BSEN/IEC 61439-2: 2009
Designation of the incoming device is defined by the selection of an
overcurrent release or Switch Disconnector module.
THE SWITCHING UNIT MUST BE FITTED WITH ONE OF THESE MODULES.
POWERSTAR 125
PANE LBOARDS & I NCOMI NG DEV I CE MODUL ES
