7 / 20
POWERSTAR 125
ACCESSOR I ES
5
LIGHTNING & SURGE ARRESTORS (INCOMER ONLY)
I
Description LIST No
Combination Lightning & Surge Arrestor kit-type 1/2
17
GGCLSA
Lightning Arrestor kit-type 1
17
GGLA
Surge Arrestor kit-type 2
17
GGSA
•
Lightning /Surge Arrestors include: MCCB, cabling and mounting base
•
The combination lightning & surge arrestor kit and the lightning
arrestor kit will be supplied with a new front cover in addition to the
above
•
Only one of the above options possible per panelboard
•
Kits will utilise the bottom right hand MCCB position
OUTGOING METER PACKS
I
Description LIST No
63
A CT operated Energy meter
17
GG4WCT63M
125
A CT operated Energy meter
17
GG4WCT125M
OUTGOING MID METER PACKS
I
Description LIST No
63
A CT operated Energy meter MID
17
GG4WCT63MID
125
A CT operated Energy meter MID
17
GG4WCT125MID
•
Energy meters include pulsed output, offering Amps, Volts, kWh
readout
•
Outgoing meter packs include a digital energy meter, current
transformers, terminals, wiring loom and mounting bases
Meter Pack Voltage supply cable loom
17
OUMKCL
(
only one required per bank of meters)
INCOMER INTEGRAL METER PACKS
I
Rating Description LIST No
250
A Integral CT operated Energy meter
17
GG250INCTM
400
A Integral CT operated Energy meter
17
GG400INCTM
INCOMER INTEGRAL MID METER PACKS
I
Rating Description LIST No
250
A Integral CT operated Energy meter MID
17
GG250INCTMID
400
A Integral CT operated Energy meter MID
17
GG400INCTMID
•
Integral meter packs include a digital energy meter, three current
transformers, fuses, wiring loom and mounting bases
17
GG250INCTM
CABLEWAYS
I
No. of available
Modular Height
Height (mm)
meter knockouts LIST No
3
228
NIL
17
GG03MW
12
912
6
17
GG12MW
13
988
6
17
GG13MW
14
1064
6
17
GG14MW
15
1140
6
17
GG15MW
17
1292
8
17
GG17MW
19
1444
9
17
GG19MW
•
All cableways accept the outgoing metering options below
(
not 3 module)
•
Cableways may be used with or without metering
• 250
mm wide
17
GG15MW 17GG13MW 17GG12MW
17
GG4WCT125M
17
GGSA
