12 / 20
OVERCURRENT RELEASE AND SWITCH
DISCONNECTOR MODULES FOR TP SWITCHING UNIT
l
Rated Current (
I
n) Overcurrent adjustment (0.4 to 1x
I
n) LIST No
250
A
100
A .... 250A
7
T325/OR3
400
A
160
A .... 400A
7
T340/OR3
•
Adjustable overcurrent release
•
Adjustable short circuit release
400
A
Switch Disconnector
7
T363/SD
OVERCURRENT RELEASE MODULES FOR 4P
SWITCHING UNIT
l
Rated Current (
I
n) Overcurrent adjustment (0.4 to 1x
I
n) LIST No
250
A
100
A .... 250A
7
T325/OR4
400
A
160
A .... 400A
7
T340/OR4
•
Adjustable overcurrent release
•
Adjustable short circuit release
•
Protected neutral function
• 4
P Switch Disconnector available upon request
10
173
T2406
174
T2402
7
T340/OR3
17
INMK400CT
400
A PANELBOARD WITH TP SWITCHING UNIT
l
Outgoing TP Height
ways (mm) LIST No
400
A
2 1055
173
T2402
4 1160
173
T2404
6 1265
173
T2406
• 400
A rated Panelboards
• 900
mm wide x 250mm deep (including door)
•
Busbar fault rated 35kA for 1 sec
• 250
A outgoing TP MCCBs (T2 frame size)
•
IP3X (door closed)
•
Twin 150 mm
2
4
Core Maximum on Incoming Terminals
•
M10 cable lugs maximum 30mm wide
•
BSEN/IEC 61439-2: 2009
Designation of the incoming device is defined by the selection of an
overcurrent release or Switch Disconnector module.
THE SWITCHING UNIT MUST BE FITTED WITH ONE OF THESE MODULES.
400
A PANELBOARD WITH 4P SWITCHING UNIT
l
Outgoing TP Height
ways (mm) LIST No
400
A
2 1055
174
T2402
4 1160
174
T2404
6 1265
174
T2406
• 400
A rated Panelboards
• 900
mm wide x 250mm deep (including door)
•
Busbar fault rated 35kA for 1 sec
• 250
A outgoing TP MCCBs (T2 frame size)
•
IP3X (door closed)
•
Twin 150 mm
2
4
Core Maximum on Incoming Terminals
•
M10 cable lugs maximum 30mm wide
•
BSEN/IEC 61439-2: 2009
Designation of the incoming device is defined by the selection of an
overcurrent release.
THE SWITCHING UNIT MUST BE FITTED WITH ONE OF THESE MODULES.
POWERSTAR 250
PANE LBOARDS & I NCOMI NG DEV I CE MODUL ES
INCOMER INTEGRAL METER PACKS
I
Rating Description LIST No
400
A
Integral 3 Ph CT operated Energy meter
17
INMK400CT
400
A
Integral 3 Ph CT operated Energy meter MID
17
INMK400MCT
•
Integral meter packs include a digital energy meter, current
transformers, fuses, wiring loom and mounting base plates
