LIGHTNING & SURGE ARRESTORS (INCOMER ONLY)
I
Description LIST No
Combination Lightning & Surge Arrestor kit-type 1/2
17
CSAR1/2
Lightning Arrestor kit-type 1
17
LAR1
Surge Arrestor kit-type 2
17
SAR2
•
Lightning /Surge Arrestors include: MCCB, cabling and mounting base
•
The combination lightning & surge arrestor kit and the lightning
arrestor kit will be supplied with a new front cover in addition to the
above
•
Only one of the above options possible per panelboard
•
Kits will utilise the bottom right hand MCCB position
17
SAR2
DOOR LOCKING DEVICE
l
Description LIST No
Door Cylinder Lock
16
CL
ADD ON UNITS T2 FRAME
l
Amps Outgoing Height
(
A) ways (mm) LIST No
400 8 583
17
T2408A
630 8 583
17
T2638A
• 400
A & 630A Busbars
• 400
A - 35kA Busbar fault rating. To be used in conjunction with the
400
A rated Panelboards only
• 630
A - 50kA Busbar fault rating. To be used in conjunction with the
630
A rated Panelboards only
•
Accepts T2 range of MCCBs to 250A TP only
• 900
mm wide x 250mm deep (including door)
ADD ON UNITS GG FRAME
l
Amps Outgoing Height
(
A) ways (mm) LIST No
400 4 267
17
GG404A
400 8 425
17
GG408A
400 12 583
17
GG4012A
• 400
A Busbars
•
To be used in conjunction with the 400A rated Panelboards only
•
Busbar fault rated 25kA for 1 sec
•
Accepts GG range of MCCBs (15A - 125A) SP & TP
• 900
mm wide x 250mm deep (including door)
12
17
GG408A
17
T2408A
16
CL
POWERSTAR 250
ADD ON UN I TS
