5 / 20
OVERCURRENT RELEASE AND SWITCH
DISCONNECTOR MODULES
l
Rated Current (
I
n) Overcurrent adjustment (0.4 to 1x
I
n) LIST No
250
A
100
A .... 250A
7
T325/OR3
400
A
160
A .... 400A
7
T340/OR3
•
Adjustable overcurrent release
•
Adjustable short circuit release
400
A
Switch Disconnector
7
T363/SD
POWERSTAR 125
PANE LBOARDS & I NCOMI NG DEV I CE MODUL ES
3
17
GG4012SW
7
T340/OR3
17
GG4012DC
DIMENSIONS 400A PANELBOARDS
l
LIST No Overall Height
Mod. Height (mm)
17
GG4006SW
14 1064
17
GG4008SW
15 1140
17
GG4012SW
17 1292
17
GG4016SW
19 1444
17
GG4006DC
14 1064
17
GG4008DC
15 1140
17
GG4012DC
17 1292
17
GG4016DC
19 1444
630
684 (9
Mod.)
188
400
A PANELBOARD WITH TP SWITCHING UNIT
l
Outgoing Modular Height
ways Height (mm) LIST No
400
A
6 14 1064
17
GG4006SW
8 15 1140
17
GG4008SW
12 17 1292
17
GG4012SW
16 19 1444
17
GG4016SW
• 400
A rated Panelboards
•
Busbar fault rated 25kA for 1 sec
•
IP3X (door closed)
•
Twin 150 mm
2
4
Core Maximum on Incoming Terminals
•
M10 cable lugs maximum 30mm wide
•
BSEN/IEC 61439-2: 2009
Designation of the incoming device is defined by the selection of an
overcurrent release or Switch Disconnector module.
THE SWITCHING UNIT MUST BE FITTED WITH ONE OF THESE MODULES.
400
A PANELBOARD WITH DIRECT CONNECTION
l
Inc. Terminals Outgoing Modular Height
only ways Height (mm) LIST No
400
A
6 14 1064
17
GG4006DC
8 15 1140
17
GG4008DC
12 17 1292
17
GG4012DC
16 19 1444
17
GG4016DC
• 400
A rated Panelboards
•
Busbar fault rated 25kA for 1 sec
•
IP3X (door closed)
•
Twin 150 mm
2
4
Core Maximum on Incoming Terminals
•
BS EN/IEC 61439-2: 2009
