6 / 20
ADD-ON MCCB OUTGOING HOUSINGS
I
Modular Height Height (mm) LIST No
2
off GG MCCB
3
228
17
GG125GGMB
•
Includes all interconnections
•
Busbar fault rated 25kA for 1 sec
•
GG Unit accepts SP/TP MCCBs up to 125A
•
Fits above 250A/400A Panelboards.
• 630
mm wide x 188mm deep
POWERSTAR 125 ADD - ON METER PACKS
l
An Add-on Assembly, 228mm high, to fit beneath a Panelboard,
comprising: Enclosure with slotted front plate and door, Energy Meter with
pulsed output, offering Amps, Volts and kWh readout.
3
off 250A/400A Current Transformers, with associated fuses and wiring.
LIST No
250
A
17
GG250MPKIT
400
A
17
GG400MPKIT
POWERSTAR 125 DOOR KITS
I
Description LIST No LIST No
Door kits with catch
3
module
17
GG03DR
10
module
17
GG10DR
5
module
17
GG05DR
12
module
17
GG12DR
6
module
17
GG06DR
13
module
17
GG13DR
7
module
17
GG07DR
14
module
17
GG14DR
8
module
17
GG08DR
15
module
17
GG15DR
9
module
17
GG09DR
Door Cylinder lock
16
CL
SINGLE POLE DISTRIBUTION BOARD
I
Modular
Height
Outgoing 1P ways Height (mm) LIST No
19 3
228
17
GG19DB
•
Supplied with 100A Switch Disconnector and busbar
•
Accepts up to 63A Polestar Compact and Loadstar MCBs
• 630
mm wide x 188mm deep
CONTROL MODULE ENCLOSURE
I
Modular
Height
18
mm wide modules Height (mm) LIST No
24
mod. DIN Rail 3
228
17
GG24SS
•
Accepts DIN rail mounted devices
CABLE SPREADER BOX
I
Modular
Height
Height (mm) LIST No
Empty enclosure 3
228
17
GGCSB
4
17
GG125GGMB
17
GG06DR
DIMENSIONS ADD-ON ENCLOSURES
I
LIST No Height (mm) Mod. Height
17
GG19DB
228 3
17
GG24SS
228 3
17
GGCSB
228 3
17
GG - - 0MPKIT
228 3
17
GG125GGMB
228 3
630
188
17
GG250MPKIT
17
GG24SS
POWERSTAR 125
ACCESSOR I ES
