Panelboards
(includes TP or 4P
switching unit)
TP
4P
400A NHPBJ2W400MU3
630A NHPBJ2W630MU3
400A NHPBJ2W400MU4
630A NHPBJ2W630MU4
2 way
Extension Units
G frame
Panelboard Cableways
2 way
4 way
6 way
2 way
4 way
6 way
Metered
2 way - NHPBJ2MCW
4 way - NHPBJ4MCW
6 way - NHPBJ6MCW
Standard
2 way - NHPBJ2CW
4 way - NHPBJ4CW
6 way - NHPBJ6CW
Extension Cableways
G frame
4 way
8 way
12 way
4 way
8 way
12 way
Metered
4 way - NHPBG4MCWA
8 way - NHPBG8MCWA
12 way - NHPBG12MCWA
Standard
4 way - NHPBG4CW
8 way - NHPBG8CW
12 way - NHPBG12CW
400A NHPBG4W400AU
630A NHPBG4W630AU
4 way
Outgoing Metering
Standard
MID
63A G frame Meter Kit
NHPBJOMK63
-
125A G frame Meter Kit NHPBJOMK125
NHPBJMIDOMK125
160A J frame Meter Kit
NHPBJOMK160
NHPBJMIDOMK160
250A J frame Meter Kit
NHPBJOMK250
NHPBJMIDOMK250
Each metering cableway of outgoing meter kits requires power
supply cable NHPBOCL
Outgoing
Metering
CARLOGAVAZZI
kWh
M21
Overcurrent
Release Modules
(required for each incomer)
160A - 400A
100A - 250A
Switch Disconnector
400A
160A - 400A
100A - 250A
250A - 630A
Switch Disconnector
630A
Extension Units rating must
match the rating of the
Panelboard being extended.
NH250 PANELBOARD SELECTION GUIDE
