CABLEWAYS (WITH METER KNOCK-OUTS)
PANEL BOARD AVAILABLE
CAT REF. DESCRIPTION TYPE KNOCK-OUTS
NHPB3MW 3 mod Add-on unit -
NHPB12MW 12 mod 250A 6Way 6
NHPB13MW 13 mod 250A 8Way 6
NHPB14MW 14 mod 400A 6Way 6
NHPB15MW 15 mod 250A 12W/400A 8Way 6
NHPB17MW 17 mod 250A 16W/400A 12Way 8
NHPB19MW 19 mod 400A 16Way 9
Dimensions: Height as listed, width: 250mm, depth: 180mm
ADD-ON UNITS
CAT REF. DESCRIPTION
NHPBGDB Add-on 100A SPN Distribution Board
NHPBGAB Add-on Control Module - 24 mod
NHPBG250MP Add-on 250A Panelboard Metering Kit
NHPBG400MP Add-on 400A Panelboard Metering Kit
NHPBGCSB Cable Spreader Box
Dimensions: 228mm H x 630mmW x 164mm D
DOOR KITS
PANEL BOARD
CAT REF.
DESCRIPTIONTYPE
NHPBG3DR 3 mod
Add-on Units
NHPBG5DR 5 mod
Half door - 6Way
NHPBG6DR 6 mod
Half door - 8Way
NHPBG7DR 7 mod
Half door - 250A incomer
NHPBG8DR 8 mod
Half door - 12Way
NHPBG9DR 9 mod
Half door - 400A incomer
NHPBG10DR 10 mod
Half door - 16Way
NHPBG12DR 12 mod
Full door - 250A 6Way
NHPBG13DR 13 mod
Full door - 250A 8Way
NHPBG14DR 14 mod
Full door - 400A 6Way
NHPBG15DR 15 mod
Full door - 250A 12Way/400A 8Way
NHPBDL
Standard door lock (2 keys)
NHPB3MW NHPB15MW NHPB13MW
NHPBGDB
NHPBG3DR
NHPBG10DR
