Panelboards
(includes TP switching unit)
250A NHPBG6SW250 NHPBG8SW250 NHPBG12SW250
400A NHPBG6SW400 NHPBG8SW400 NHPBG12SW400
6 way
8 way
12 way
Overcurrent Release Modules
(required for each incomer)
TP
Cableways
3 mod
12 mod
17 mod
Add-on unit
NHPB3MW
250A 6 Way
NHPB12MW
250A 8 Way
NHPB13MW
400A 6 Way
NHPB14MW
250A 12 Way/400A 8 Way NHPB15MW
250A 16 Way/400A 12 Way NHPB17MW
400A 16 Way
NHPB19MW
Outgoing Metering
Standard
MID
Meter Kit
Meter Kit
63A
NHPB63CTM
-
125A
NHPB125CTM NHPB125CTMID
Each metering cableway of outgoing meter
kits requires power supply cable NHPBOCL
CARLOGAVAZZI
kWh
M21
Integral Incoming Meter Kits
250A
400A
Std
NHPB250CTINM
NHPB400CTINM
MID
NHPB250CTINMID NHPB400CTINMID
CARLOGAVAZZI
kWh
M21
Add-on Units
Add-on 100A SPN Distribution Board
Add-on Control Module - 24 mod
Add-on 250A Panelboard Metering Kit
Add-on 400A Panelboard Metering Kit
Cable Spreader Box
250A
400A
63A - 160A
NHJ631603ELI -
100A - 250A
NHJ1002503ELI NHL1002503ELI
160A - 400A
-
NHL1604003ELI
Switch Disconnector NHJ2503SWDM NHL630SWDM
30
NH125 PANELBOARD SELECTION GUIDE
