NH RCBOs,
Modular Devices & Accessories
MODULAR DIN RAIL DEVICES
CAT REF. DESCRIPTION MODULE
SMSCD11 DigitalTimeclock 1 channel 1xNO/NC Contact 16A 1
TMSCD21 DigitalTimeclock 1 channel 1xNO Contact 16A 2
TMTCD22 DigitalTimeclock 2 channel 2
MESB-20NC 20A 2 Pole Contactor 2 x N/C 240V Coil 1
MESB-20NO 20A 2 Pole Contactor 2 x N/O 240V Coil 1
MESB-24NC 24A 4 Pole Contactor 4 x N/C 240V Coil 2
MESB-24NO 24A 4 Pole Contactor 4 x N/O 240V Coil 2
MESB-40NC 40A 4 Pole Contactor 4 x N/C 240V Coil 3
MESB-40NO 40A 4 Pole Contactor 4 x N/O 240V Coil 3
MESB-63NO 63A 4 Pole Contactor 4 x N/O 240V Coil 3
For use in DIN Enclosures EG: NH ED Range, Flexible CUs or ‘+’ Units
SINGLE MODULE RCBO
-
FOR USE IN NHTYPE A & B DISTRIBUTION BOARDS
RATING POLES RCD RATING B CURVE C CURVE
6A 10kA 1 30mA PSBS6-B/1 PSBS6/1
10A 10kA 1 30mA PSBS10-B/1 PSBS10/1
16A 10kA 1 30mA PSBS16-B/1 PSBS16/1
20A 10kA 1 30mA PSBS20-B/1 PSBS20/1
32A 10kA 1 30mA PSBS32-B/1 PSBS32/1
40A 10kA 1 30mA PSBS40-B/1 PSBS40/1
50A 10kA 1 30mA PSBS50-B/1 PSBS50/1
RCBOs with longer incoming neutral flying leads (1.2M) are available - Suffix the
Type C list number with LT (e.g. PSBS6/1LT)
KILOWATT HOUR METERS
CAT REF.
DESCRIPTION
MODULE
NHCM80SP
80A SP kWh Meter
2
NHCM80TP
80ATP kWh Meter
4
NHMID80SP 80A SP kWh (MIDApproved) Meter
2
NHMID80TP 80ATP kWh (MIDApproved) Meter
4
l
Direct Connected Digital kWh meter
l
Pulsed output for BMS monitoring
l
DIN Rail mounting
For use in DIN enclosures eg: NHAB
MID approval - see Technical section page 75.
NHCM80SP NHCM80TP
ACCESSORIES
CAT REF DESCRIPTION
NHEP11 Replacement gland plate
NHBL1 1 Module blank
NHBL3 3 Module blank
NHBL6 6 Module blank
NHBL9 9 Module blank
NHBLM1 1 Module MCB dummy blank
NH00PP Blanking plate -Twist fit
NH18BB1 9 busbar insulators
MCBLDX Locking device for MCB
WPL Padlock for MCBLDX
NHPBDL MCB Board lock
PDDPL Door lock with padlocking device
NHCEKIT 14 terminal clean earth kit
NHCEKIT20 20 terminal clean earth kit
NHMSL Locking device for incoming switch
NHBBTOK Busbar tap off kit
MCBLDX WPL NHBL1 NH00PP NHBLM1
