MASTER MHN-SA
Product Description
•Compact quartz metal halide lamps with
double-pinch
Product Benefits
•Allows compact and very e cient luminaire
systems with high precision optics for good
beam control and minimal spill light
•Very good colour rendering creates a
pleasant ambience with high visual comfort
for players and spectators
•Continuous spectral distribution o ers a
superior solution for (semi-) professional
stadiums with regular TV coverage
Product Features
•Very compact source (Short Arc) with
high luminous e cacy and superior colour
rendering
•Double-pinch concept results in long lifetime
•Natural white colour appearance, high
colour rendering and good colour stability
•Daylight colour temperature eases transition
from daylight to artificial lighting
Environment
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Professional sports lighting and floodlighting
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
X
D
O
A
C
Dim. A C D O X
no. nom. max. max. nom. nom.
1 318 369 41.0 25 25
2 226 369 34.3 25 34
3 226 369 41.0 25 25
C
O
D
Dim. C D O
no. max. max. nom.
4 364 41 25
MASTER MHN-SA Clear
Wattage/
Colour Code
Cap-
Base
Vol-
tage
Lamp
Lumi-
nous
Flux EM
Life to
10%
failures
Life to
50%
failures
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering number
(V) (lm) (h) (h)
1800W/956 X830R 230 155,000 2,300 5,000 p15 A+ 1 NO / 1 1 1800MHNSA956R 871150020106500 yes
1800W/956 (P)SFC 230 155,000 2,000 6,100 p15 A+ 4 NO / 1 1 1800MHNSA956 871150020075400 yes
1800W/956 (P)SFC 400 160,000 2,400 6,100 p15 A+ 4 NO / 1 1 4151800MHNSA956 871150020076100 yes
2000W/956 X830R 400 226,000 2,300 5,000 p15 A+ 2 UNP / 1 1 2000MHNSA956HO 871829124183600 yes
2000W/956 X830R 400 200,000 1,400 3,700 p15 A+ 3 NO / 1 1 2000MHNSA956 871150020079200 yes
MASTER MHN-LA
D
X A
O
Dim. A D O X
no. nom. max. nom. nom.
1 294 40 40.5 35
2 364 40 108.0 58
Product Description
•Compact quartz metal halide lamps with
double-pinch
Product Benefits
•Allows compact and e cient luminaire
systems with precision optics for good beam
control and minimal spill light
•Good colour rendering creates a pleasant
ambience with high visual comfort for
players and spectators
•Continuous spectral distribution o ers
options for semi-professional stadiums and
for professional stadiums with regular TV
coverage
Product Features
•Compact source (Long Arc) with high
luminous e cacy
•Double-pinch concept results in long lifetime
•Natural white colour appearance, high
colour rendering and good colour stability
•Daylight colour temperature eases transition
from daylight to artificial lighting
Environment
•This product is RoHS compliant.
•This product is covered by WEEE
Application
•Professional and semi-professional sports
lighting and floodlighting
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
