MASTER CityWhite CDO-TT
The easiest switch to comfortable white light
Ceramic metal halide lamp with clear tubular
outer bulb shape, used in outdoor o ering
pleasant white light
Product Benefits
•White warm colour impression providing
comfort and safety
•Easy upgrade from SON to white light
without additional cost
•Flexible light levels and reduced energy
consumption possible via dimming option
Product Features
•High-quality white light
•Directly retrofit on HPS (SON/NAV)
installations for upgrade from yellow to
white light
•"Plus" concept with high e cacy translates
into high light output and improved lumen
maintenance
•Good colour rendering and harmonized
warm white colour temperature
•Dimmable
Environment
•Good environmental choice because of high
energy e ficiency in white light
•Products are RoHS compliant
•Products are covered by WEEE
Application
•Beautification and functional lighting for City
centers, shopping centers and pedestrian
areas, residential areas, road lighting and
floodlighting
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Lamps may use electronic or electromag-
netic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
D
L
C
O
Dim. C D L O
no. max. max. nom. nom.
1 156 36 102 5.25
2 156 36 102 7.15
D
L
C
O
Dim. C D L O
no. max. max. nom. nom.
3 211 47 132 8.5
4 211 47 132 10.0
5 257 47 157 12.1
MASTER CityWhite CDO-TT Plus Clear
Wattage/
Colour Code
Cap-
Base
Luminous
Flux EM
25°C, Rated
Life to 10%
failures
Life to 50%
failures
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order Code Ordering
number
8718291...
(lm) (h) (h)
50W/828 ES 5,500 12,000 20,000 any A+ 1 1SL / 12 12 50CDOTTPLUS828 18561100 yes
70W/828 ES 7,500 12,000 27,000 any A+ 2 1SL / 12 12 70CDOTTPLUS828 12030800 yes
100W/828 GES 10,700 18,000 27,000 any A+ 3 1SL / 12 12 100CDOTTPLUS828 12032200 yes
150W/828 GES 16,500 18,000 27,000 any A+ 4 1SL / 12 12 150CDOTTPLUS828 12034600 yes
250W/830 GES 28,300 16,000 23,000 any A+ 5 1SL / 12 12 250CDOTTPLUS830 12197800 yes
