MASTER CosmoWhite CPO-TT Xtra
The easy-fitting solution for highly
energy-e cient and reliable white light
outdoors
New-generation ceramic metal-halide tubular
lamps used in outdoor applications, o ering
e cient and pleasant white light
Product Benefits
•Attractive white-light alternative to current
standard mercury-vapor, HPS and ceramic
solutions
•O ering easy access to low-cost high-
performance new system with existing
standard components
•Best combination of low investment and
high energy savings (up to 65%), resulting in
very low cost of ownership
Product Features
•Highly e cient white light; extremely high
system e cacy
•Long reliable lifetime; new Xtra range
o ering service life of up to 6 years (> 30kh
average life)
•Unique new burner design in combination
with glass outer bulb and Edison lamp base
o ering easy fit into existing HPS / SON
luminaire platform
•Designed for electronic gear platforms
including all control features and dimming
options o ering flexible light levels and
reduced energy consumption
Environment
Philips Green product with highest e cacy:
minimises environmental impact and CO2
emissions:
•Good environmental choice due to high
energy e ciency in combination with
easy-to-install white light
•RoHS-compliant (lead-free), very low
mercury content (max. 2.5 mg), covered by
WEEE
Application
•Street lighting and area lighting, urban
and residential areas and city centers; for
functional lighting and city beautification
Warnings and Safety
•Use only in a totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Use only with suitable electronic control
gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
•E27 lamp holders and other parts in
luminaires should be designed to withstand
the ignition voltage of the electronic control
gear (rated at 5 kV ignition pulse)
D
L
C
O
Dim. C D L O
no. max. nom. nom. nom.
1 156 35 103 14
2 156 35 102 14
3 211 46 132 18
D
L
C
O
Dim. C D L O
no. max. nom. nom. nom.
4 211 46 132 22
D
L
C
O
Dim. C D L O
no. max. nom. nom. nom.
5 257 46 157 12.3
6 257 46 162 14.0
MASTER CosmoWhite CPO-TT Xtra Clear
Wattage/Colour
Code
Cap-Base Lum. Flux
EL25°C, Rat.
horiz.
Life to 10%
failures,
horiz.
Burning
Position
Dim. no. Packing type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(lm) (h)
45W/628 ES 4,650 24,000 p20 A+ 1 1SL / 12 12 45CPOTT628 69171600
60W/628 ES 7,090 24,000 p20 A+ 2 1SL / 12 12 60CPOTT628 69034400
90W/628 GES 10,140 20,000 p20 A+ 3 1SL / 12 12 90CPOTT628 68115100
140W/628 GES 16,000 16,000 p20 A+ 4 1SL / 12 12 140CPOTT628 69032000
210W/942 GES 22,000 15,800 any A+ 5 1SL / 12 12 210CPOTT942 69105100
315W/942 GES 34,750 15,900 any A+ 6 1SL / 12 12 315CPOTT942 69107500
